US$4,000.00-8,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
C6241 C6246 C6256 C6266
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Controlling Mode
Artificial
Certification
CE, RoHS, ISO 9001
Swing Over Cross Slide
220mm
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
METAL LATHE MACHINE FEATURES:
The guide way and all gears in the head stock are hardened and precision ground.
The spindle system is high rigidity and accuracy.
The machines have powerful head stock gear train, high rotating accuracy and smooth running with low noise.
An overload safety device is provided on the apron.
Pedal or electromagnetic braking device.
Tolerance test certificate, test flow chart included
SPECIFICATIONS:
| SPECIFICATION | MODEL |
| C6241×1000 | C6241V×1500 | C6246×2000 | C6246V×1000 | C6246V×1500 | C6246V×2000 |
| Capacity | |
| Swing over bed | 410 | 460 |
| Swing over cross slide | 220 | 270 |
| Swing in gap diameter | 640 | 690 |
| Distance between centers | 1000 | 1500 | 2000 | 1000 | 1500 | 2000 |
| Valid length of gap | 165mm |
| Width of bed | 300mm |
| Headstock | |
| Spindle nose | D1-6 |
| Spindle bore | 58mm |
| Taper of spindle bore | No.6 Morse |
| Range of spindle speed | 12 changes, 25~2000r/min |
| Feeds and threads | |
| Compound rest travel | 128mm |
| Cross slide travel | 285mm |
| Max.section of tool | 25×25mm |
| Lead screw thread | 6mm or 4T.P.I. |
| Longitudinal feeds range | 42 kinds, 0.031~1.7mm/rev(0.0011"~0.0633"/rev) |
| Cross feeds range | 42 kinds, 0.014~0.784mm/rev(0.00033"~0.01837"/rev) |
| Threads metric pitches | 41 kinds, 0.1~14mm |
| Threads imperial pitches | 60 kinds, 2~112T.P.I. |
| Threads diametral pitches | 50 kinds, 4~112DP |
| Threads module pitches | 34 kinds, 0.1~7MP |
| Tailstock | |
| Quill diameter | 60mm |
| Quill travel | 130mm |
| Quill taper | No.4 Morse |
| Motor | |
| Main motor power | 5.5kW(7.5HP) 3PH |
| Coolant pump power | 0.1kW(1/8HP) 3PH |
| Dimension and weight | |
| Overall dimension(L×W×H) | 220×108×134 | 275×108×13 | 325×108×134 | 220×108×137 | 275×108×137 | 325×108×137 |
| Packing size(L×W×H) | 225×112×162 | 280×112×156 | 330×113×156 | 225×112×162 | 280×112×156 | 330×113×156 |
| Net weight | 1580kg | 1745kg | 1900kg | 1645kg | 1810kg | 1965kg |
| Gross weight | 1845kg | 2050kg | 2230kg | 1910kg | 2115kg | 2295kg |
>>
