Basic Info.
Operating System
Windows10
Dimensional Accuracy
±0.05mm
Scanning System
High-Precision Scanning Mirror Laser
Transport Package
Wooden Box Packaging
Specification
2720mmx1463mmx2861mm
Trademark
Global Laser Box
Product Description
Product Description
1. Big enclosed size: using integrated design, very easy to operate. 2. Simple operation: the software interface is friendly and easy to learn; integrated automatic centering function, the operator can easily place the crystal. 3. Strong adaptability: according to the movable requirements of the machine, the core components are equipped with a shock-proof system, which can effectively prevent damage to the core components of the machine due to accidental impact during equipment transportation and use. 4. Fast engraving speed: using galvanometer laser high-speed scanning working mode, the speed can reach up to 300,000 points/min, saving engraving time. 5. High stability and delicate engraving effect: using advanced air-cooled semiconductor end-pumped solid-state laser technology. 6. Adopt sealed integrated design, good beam quality, high stability, and delicate engraved dots. Can work stably for a long time. Product Parameters
GLB-750M |
Basic Size |
Equipment Size | 2720mm×1463mm×2861mm |
Print size | 720mm×360mm×300mm |
Machine Weight | 200KG |
Performance Parameters |
Powder Layer Thickness | 0.03mm/0.1mm |
Powder Delivery Method | Dual top powder supply |
Powder Spread Method | Bidirectional circulation powder spread |
Scanning Speed | 7-12m/s |
Dimensional Accuracy | ±0.05mm |
Supervisory Software | Independently developed by GLOBAL LASER BOX |
Supported Interface Types | RS232/RS485,Ethernet,USB,Canopen |
Human-Machine Interaction Device | PC |
Operating System | Windows10 |
Communication Protocol |
between Upper and Lower Computers | Modbus Standard Protocol |
Driving Component | Servo Motor |
Control Software | Independently developed by GLOBAL LASER BOX(YM BuildIII) |
Data Processing Software | VoxelDance |
Optical Performance |
Laser System | Fiber Laser |
Scanning System | High-precision Scanning Mirror Laser |
Beam Diameter | 70-100μm |
Laser Power | 500W×4/500W×8(optionalyconfgurnd) |
Laser Control System | RTC5 |
System Protection and |
Energy Consumption |
Protective Gas | Nitrogen,Argon |
Gas Protection System | Gas Flat Flow Smoke and Dust Recovery System |
Equipment Power | 3KW |
Operating Environment | Temperature 25±3ºC,Humidity <75% |
Supported Print File Format | STL |
Automatic Setup and Monitoring Alarm Supported |
Company Profile
FAQ 1. What is the electrical configuration to install to power the machine, socket, power supply, electrical safety
• 120 M
Voltage 220V the socket can change local standards
• water cooling
Voltage 220V
• powder collector
Link the printer for power supply
2. Slicer software
• price
$1500/Year,$7000/Life time
• who does the maintenance
Software company
• Cost of maintenance and update
The fee includes maintenance and updates.
3. Information on chrome cobalt and titanium powders
• Heat treatment process for framework and coping/full unit and long bridge
Different powder have different heat treatment powder temperatures.
It is only related to the materials and has no relation to the printed products.
• Different granulometry offered
15-53μm
• Photo for marketing
• Packaging I must personalize
I do not recommend changing the manufacturer's name and logo
Because it involves a certificate.
4. Support disc chrome cobalt and titanium
• Thickness
20mm
• Fixing in the machine
Magnetic
• How many prints to recommend
Recommended printing times: over 200 times; grinding amount: remaining 8-9mm.
• How to surface after printing
Grinding bed, Hand Grinder
5. Photos and video of the technical parts of the machine
• Electrical compartment
• Laser compartment
• Filtration compartment
not available for now
6. Maintenance after photo and video printing
• Time for cleaning before reprinting
Cleaning time before reprinting: Clean the forming chamber for ten minutes.
• Annual maintenance
The permanent filter cartridge requires no maintenance and can print over 20,000 times.
• Cleaning the powder collector
Permanent filter element does not require cleaning.
• Water level of the water cooling
Add purified water above green.
7. Surveillance camera information
• Remote connection to PC and telephone
• Send a video so that I can check
8. Chrome printing times and quantity cobalt and titanium
• Framework
7-8
• Coping and full
80-90
9. how long is the training
• learn the slicer
• learn the machine software
• learn the machine start-up
• learn the post-processing
• learn the machine cleaning and collector
• learn the annual maintenance
About 3 days
>>
