| LX1 |
| Outside size | 7000×5200×3400mm(L×W×H) |
| Inside size | 6900×3900×2650mm(L×W×H) |
| Entrance door | 3 folds,3000x2600 mm(W×H), bending steel door,cast aluminum hinge, tempered glass window |
| Emergency door | 650*2000mm(W*H),with pressure lock,with glass window,with step |
| Main System |
| Cabin system | Wall panel | -Sandwich style EPS 50mm,0.4mm thick steel, anti-flame and heat-insulation.
-High quality galvanized steel roof panel. |
| | Basement | Optional |
| Ventilation system | Inlet fan | Optional |
| | Outlet fan | 1 set European-style exhaust air fan, air capacity:18000m³/h. Large air volume and low noise. |
| | Cabinet setting type | -Exhaust air from back downside,adopt powder quadrate steel frame , strong and beautiful .
-Cabinet for the fan*1unit ,air duct *2units,
-Elbow: 90°*1 unit |
| | Airflow speed | On load 0.3m/s,ventilation rate:280time/h |
| Heating system | Optional : Movable infrared baking lamps(3 lamps or 6 lamps) |
| Lighting system | Ceiling lights | 32pcs*16w LED lighting |
| | Side lights | Optional |
| Filtering system | Primary filter | Grade G2 plate type , filtering rate>83% |
| | Floor filter | Multi-layer fiberglass filter,filtering rate>70% |
| Control system | Control panel | Intelligent control system |
| | Function | Lighting,painting, Overload, lack of phase protection |
| Total power | 6KW |
| Voltage/Frequency | 380V,50HZ,3 phase |
| |
