DVB-T Antenna with Coaxial Cable 1.5c 2V for 75 Ohms

Product Description

company information Antenna Technology is a high-teach company in Guangdong Province. It is professionally engaged in designing, manufacturing and selling Car Antenna and mobile communication products, we always keep an eye on your demands and the developing trend of this industry, and have established a complete products system of car antenna.
Our company has 10 years experience in manufacturing car antenna.The superior engineers provide precondition for product innovation, perfect production and testing equipment provide the quality guarantee for our products.
As the international enterprise, we are aiming at bringing customers the highest quality products to satisfy your expectation and needs, a large group of skilled technician work hard in order to increase the benefit for customers.
specification

Origin	China
Brand	ATC
Model	ATC-V08B-1
Frequency	40-870MHz
Certification	ROHS
Packing	Poly Bag/Color Box/Double Blister
VSWR	3:1
Antenna Amplifier gain	19.50±2dB, at 174MHz
	19.10±2dB, at 230MHz
	17.30±2dB, at 460MHz
	15.80±2dB, at 588MHz
	12.50±2dB, at 870MHz
Antenna Mast Extension Length	118.7±5.0mm
Shrink length	55.70±2mm
Base Diameter	29.60mm with ferrites magnet
Cable Length	4.5 meters
Coaxial Cable Type	1.5C 2V
Cable Impedance	75 Ohms
Warranty	3 years

packing
pratical application

---
