Mobile Drum Wood Chipper Shredder with Diesel Engine Capacity 10-15 T/H Wood Log Chipper

Product Description

Mobile Drum Wood Chipper Shredder With Diesel Engine Capacity 10-15 t/h Wood Log Chipper
Product Description
Product Introduction
1.It is one special equipment for high quality wood chips. It is widely used to make the flake board, fiber board, building materials.
2.The drum chipper is of compact structure, easy operation, high capacity, wide raw materials adaptability, high quality, safe and reliable,convenient maintenance.
Product Parameters

Model	BX-315	BX-316	BX-318	BX-2113	BX-3113
Power of main motor(kw)	30	45	55	110	220
Q'T'Y of flying blades(pcs)	4	4	4	4	4
Opener size(mm)	300*150	400*170	540*220	680*270	700*400
Input max diameter(mm)	130	150	200	250	300
Length of chips(mm)	10-20	10-20	10-20	15-25	15-20
Capacity(tons/h)	2-3	3-5	8-12	15-25	25-35
Dimension of main machine(m)	2.5*1.7*1.3	2.6*1.8*1.4	3.1*2.0*1.5	3.5*2.18*1.8	3.68*2.45*2.05
Weight of main machine(kg)	2200	3380	4680	8320	11850
Input belt conveyor (m)	4*0.3	4*0.4	6*0.55	6*0.7	8*0.72
Discharging belt conveyor(m)	10*0.4	10*0.5	10*0.6	10*0.8	10*0.8

Main Features 1) Simple structure in linear type ,easy in installation and maintation. 2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts. 3) High pressure double crank to control the die opening and closing. 4) Running in a high automatization and intellectualization,no pollution 5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine.
Raw Materials & Final Products
Other Type Wood Chipper

PTO/Tractor Driven Type Wood Chipper

Diesel Engine Drive Wood Chipper

Disc Type Wood Chipper

Packaging & Shipping
Company Profile
Zhengzhou Leabon Machinery Equipment Co., Ltd. established in 2011, is located in Zhengzhou City, enjoying convenient transportation and superior geographical position. Leabon machinery has a perfect quality control and after-sales service system, and the products have passed CE certification. Leabon Machinery specializes in the manufacture, installation and debugging of wood pellet producing line, feed pellet production line and farm machinery. They have been exported to over 50 countries around the world, across continents of Europe, Asia, Africa, America and Oceania. Relying on strong research and development capabilities, our factory successfully transformed a number of new technologies into new products with autonomy, and bring them to the market, which are highly praised by customers and long-term partners. So far, Leabon Machinery has built a professional international sales team and service team that ensure fast and effective communication with different clients, also has established long-term and reliable cooperation with professional packing and shipping company. This ensures fast, safe and timely shipment for different clients. Moreover, Leabon Machinery has been developed into a global company, a professional and advanced manufacturer and exporter strong factory strength; perfect sales network; efficiently work group; fast delivery and professional transportation. We believe, honest strengthens the basis innovation leads to the future development. We sincerely thank old and new customers' cooperation and support. Welcome to visit us, at any time!
Recommended by seller

Log Peeler/Debarker

Wood Chip Hammer Mill

Wood Pellet Machine

Pls click "Send" ask for more information and EXW price if you are interested in our Wood Chip Machine/Wood Chipper.

---
