| Display Pane | Brand | MEKTmignyike |
| Model | P101WX | |
| Size/Proportion | 10.1 inch 16:10 | |
| Resolution | 1280*800 | |
| Brightness | 300cd/㎡(Can be customized 1000cd/㎡) | |
| Contrast | 800:1 | |
| Cisplay color | 16.7m | |
| Response time | 3-5ms | |
| Visible angle | 85/85/85/85(Typ.CR≥10) | |
| Pixel pitch(mm) | 0.1695（h）x0.1695（v） | |
| Draw quality | 3D noise reduction, high-definition signal, progressive scan | |
| Touch Function | Touch screen | Capacitive touch screen (10 points) |
| Surface hardness | ≥6h | |
| Transmittance | ＞95% | |
| Positioning accuracy | less than 2mm | |
| Click lifetime | > 60 million times | |
| Touch medium | Current sensing, capacitive touch pen, finger | |
| Right-click function | Click on a certain point and press for more than 3 seconds | |
| Touch interface | USB (optional COM) | |
| Motherboard Function | Refresh frequency | 60Hz |
| Power input | DC12-36V | |
| Functional interface | HD，DP，VGA，Audio | |
| Work Environment | Operating Temperature/humidity | -10℃ to +60℃/ 0-80% relative humidity, no condensation |
| Storage Temperature/humidity | -15℃ to +65℃/ 0-90% relative humidity, no condensation | |
| Product Service | After service | one-year warranty and lifelong maintenance |
| Customized service | OEM/ODM is available for material, appearance, dimensions, wide temperature, outdoor highlight, wide voltage, etc. |
