Klt-H5mf-Ov5640-1b V1.0 5MP Ov5640-1b Mipi-Schnittstelle M12 Fester Fokus Kameramodul

Product Description

5MP OV5640-1B MIPI-Schnittstelle M12 Fester Fokus Kameramodul
Kameramodul Nr. KLT-H5MF-OV5640-1B V1.0

Kameramodul Nr.	KLT-H5MF-OV5640-1B V1.0
Auflösung	5MP
Bildsensor	OV5640-1B
Sensorart	1/4"
Pixel Größe	1.4 um x 1.4 um
EFL	1.76 mm
F.NO	2.70
Pixel	2592 x 1944
Betrachtungswinkel	162.4°(DFOV) 124.0°(HFOV) 91.0°(VFOV)
Linsenabmessungen	13.60 x 13.60 x 17.10 mm
Modulgröße	77.40 x 13.60 mm
Modultyp	Fester Fokus
Schnittstelle	MIPI
Autofokus-VCM-Treiber-IC	Eingebettet
Linsenmodell	KLT-LENS-TRC-4008K1-01
Linsentyp	650 nm IR-Schnitt
Betriebstemperatur	-30°C to +70°C
Gegenstecker	DF30FC-24DS-0.4V
