Product Details
Product Description
Product Description
ZYUC series require inlet water is distilled water/deionized water / RO , produce 10-18.25MΩ.cm ultrapure water for HPLC, AA, IC, AES and a variety of experiments. There are PLC automatic control system and LCD display to ensure operating easily.
Model list
Model
| ZYUC-I-90L
| ZYUC-II-90L
| ZYUC-III-90L
| ZYUC-IV-90L
|
Inlet water source
| Distilled water/RO pure water/deionized water Microorganisms <50cfu/ml、TOC<30ppb、conductivity<15μS/cm（online）
|
Fiow rate
| 1.2-2.0 L/M( full pure water in tank)
|
UP quality
（MΩ.cm）
| Resistivity 18.25MΩ.cm (online )
Micro particulate matter (≥0.2um)<1/ml
heavy metal ions<0.1ppb
microorganisms<1cfu/ml
|
T0C Level
| TOC <10ppb
| TOC <3ppb
| TOC <10ppb
| TOC <3ppb
|
Pyrogen (endotoxin)
| ---------------
| ---------------
| ≤0.001EU/ml
| ≤0.001EU/ml
|
Configuration
| single display
| MF+UV
| MF+UF
| MF+UV+UF
|
Product size(mm)
| 510*380*560(Bentop)
|
Product weight(kg)
| 35-40kg(Bentop)
|
Power(W)
| 30W-50W(Bentop)
|
Application
| 1. Preparation of chemical solutions, biochemical analysis of biochemical reagents; 2. Routine physical and chemical detection of
buffer; 3. Routine quantitative analysis such as physical and chemical testing 4. Atomic absorption (AA), atomic emission (AES);
5. High performance liquid chromatography (HPLC), ion chromatography (IC), mass spectrometry (MC); 6. For analysis of instruments
such as plasma emission spectrometry (ICP).
|
Water storage tank
| A. Standard 30L PE water storage tank;
|
Product features
* Power on self test and water shortage protection;
* Mixed bed polishing resin;
* Automatic water absorption circulation system;
* Raw water conductivity monitor online;
* 0.2um terminal filter filtrate bacteria and virus;
* UV lamp(185nm&254nm) effeciently disinfect the UP water and reduce TOC;
* MWCO5000DUF ultrafiltration module filtrate endotoxin; so it can be used for cell culture and IVF.
The process flow
1. Ultra pure system: Ion exchange resin using H + exchange cation out the water in the filter ,using OH- exchange anions out the
water , the replaced H + and OH- combined to produce H2O, ultra-purified column filling the United States Dow UPW-450 Ultra-pure
water for nuclear grade resin, the water resistance of up to 18.25 MΩ.cm.
2. UV lamp
disinfection; ensure the TOC can less than 5ppb.
3. UF module
5000dalton; filtrate bacteria, endotoxin, microorganism, etc.
4. Terminal filter
0.2um; filtrate colloid, virus and other inpurities whose diameter is less than 0.2um.
