PP String Wound Filter Cartridges 5micron 40 Inch 226 Flat for Oilfield

Product Description

MFF Series Pleated Filter Cartridges are used for filtration of oilfield fluids. Its fully thermal welded construction ensures safe operation and optimum filtration performance. The fully thermal welded construction ensures safe usage in filtration with high temperature fluids, acids, diesel, oily water, and solvents. The high performance 3-layers media construction generally have a higher dirt-holding capacity in part due to the more consistent pore size throughout the media with larger filtration area at an absolute rating of beta5000 (99.98% effective efficiency). As the synthetic fibers are smaller than cellulose fibers, they can be packed tightly together, creating more pores in which to trap and hold particles. Synthetic fibers also perform better in harsh environments that tend to destroy cellulose filters. MFF series is manufactured with a rigid outer cage, ideally suitable for use in harsh oilfield environments and available in a wide range of microns, contributing to the protection of oilfield formations.
Applications
· Completion fluids · Work over fluids
· Gravel pack fluids · Waste water
· Surface water intake · Polishing brines
· Gels, amines & glycols · Process water
· Pre filtration RO · Stimulation fluids
· Acids · Pre filtration RO
· Oily Water Treatment

Features
· Large filter area and depth filtration provides a long life time of pleated filter cartridge
· Fully thermally welded,no glue or adhesives
· Beta5000(efficiency 99.98%) for Glass fiber media
· Low cost because of large filter area and reduces labor costs to change
· Three layers construction: Glass fiber media with PET support layer for maximum removal performance,strength and stability
Product Specification

Material of Constructions	Media	PP, PET, Glass Fiber
	End Cap Material	PP
	Center Core	PP
	Netting	PE
	Sealing	Silicone, EPDM, NBR, FKM
Dimensions	Length	30", 40"
	Outer Diameter	66mm, 69mm
	Inner Diameter	28mm
Performance	change out differential pressure	35psi(2.5Bar)
	Max. working Temperature	80ºC
	Max. Differential pressure	5.5 bar @ 25ºC
	Filtration Efficiency	Beta: 5000(99.98% removal efficiency) for glass fiber media

Flow Rate
Ordering Information
Other Popular Products
About Us
We are the pioneer and leading manufacturer for filter industry. Over the past 25 years, Darlly has grown from 4 employees to more than 500 employees. We have US and EU R&D center and warehouses. We focus on technology innovation and devote to supply best eco-friendly filtration solutions to all the industries. Based on comprehensive process knowledge, we provide variety of standard filter products, not only supply standard filtration products for customer's selection, but also design and customize according to customer's requirements. We are a high-tech company focusing on quality with competitive price.Filtering everything is our mission, let's work together to make the world cleaner.

---
