US$10,200.00-21,800.00
|
1 Piece
(MOQ)
|
Basic Info.
Type
Worktable Milling Machine
Milling Cutter Type
Vertical Milling Cutter
Automatic Grade
Semiautomatic
Certification
GS, CE, RoHS, ISO 9001
Rough Milling Cutting Depth
1.0-3.0mm
Finished Milling Cutting Depth
0.01-0.50mm
Cutting Length & Width Max
Surface: 3000-1800mm Side:1800*1800mm-1800*3000mm
Max Thickness of Workpiece
Surface: 1000mm Side: 650mm
Double Columns Gas
1800mm
Max Loading Weight
12000kg
Vertical Gear Box Spindle Power
15kw
Vertical Gear Box Spindle Cutting Diamet
250mm
Side Gear Box Spindle Cutting Diameter
200mm
Accuracy for Dimension
0.03mm/1000mm
Transport Package
Wooden or Steel Box
Production Capacity
15000sets/Year
Packaging & Delivery
Package Size
340.00cm * 200.00cm * 370.00cm
Package Gross Weight
21200.000kg
Product Description
Product Description
Es Top: Professional made the excellent machine.
Dongguan ESTOP Machinery Co., Ltd. Model: VM-1830NCS
CNC Precision Vertical Milling Machine VM-1830NCS
CNC system once setting and automatic guides where work-piece loading place, automatic measurement, automatic process from rough machining to finishing machining, which can reduce working strength of operator and increase productivity, maintain high accuracy for dimension and flatness.
Product Parameters
Specification: Main technical parameters
Specifications of CNC Precision Vertical Milling Machine VM-1830NCS |
Items | Name | Specification |
CNC Precision Vertical Milling Machine VM-1830NCS | VM-1830NCS |
Cutting capacity | Control axis number | 3 |
Rough milling cutting depth mm | 1.0-3.0 |
Finished milling cutting depth mm | 0.01-0.50 |
Cutting length & width max mm | Surface 3000-1800 Side 1800*1800-1800*3000 |
Max thickness of workpiece mm | Surface 1000 Side 650 |
Double columns gas mm | 1800 |
Worktable | Dimensions mm | 3000*1400 |
Max loading weight Kg | 12000 |
Magnetic chuck System | Permanent magnet 3000*1400mm |
Vertical Gear Box Spindle | Spindle speed(Infinitely variable speeds) rpm: | 50-500 |
Spindle power Kw | 15 |
Spindle taper | BT50 (7:24) |
Cutting diameter mm | 250 |
Side Gear Box Spindle | Spindle speed rpm: | L/H 6 speed |
Spindle power Kw | 15 |
Spindle taper | BT50 (7:24) |
Cutting diameter mm | 200 |
X/Y/Z axis | X/Y/Z axis motor power Kw | 3.0/3.0/3.0 |
X/Y/Z Max feed speed mm/min: | 8000/8000/8000 |
Z axis | Z Max cutting speed mm/min: | 6000 |
Accuracy | Flatness mm/1000mm | 0.03 |
Accuracy for dimension mm/1000mm | 0.03 |
Tank capacity | Lubrication oil tank L | 3 |
Power | Power | AC380V/200 50KVA |
Others | Spaces (Square meter m2) | 7.8*3.7 |
Machine net weight KG | 21000 |
Our Main Products: High precision machining centers, Surface Grinding machine, Gantry grinding machine, NC band saw machine, CNC Circular plate sawing, CNC Vertical milling machine, CNC Duplex milling machine, Deep hole drilling machine, Horizontal milling centers, Vertical machining centers, High speed CNC turning centers, High Precision 5-Axis Vertical Machining Center We can customize models according to customer requirements, more Non-standard series please contact us. Our Advantages
Our Service
Speed up your production and Achieve high quality with ESTopCNC CNC twin head milling machine. Revolutionizes your factory with ESTopCNC machine.
Installation:
You have decided to purchase products from ESTOP and now want to ensure that they are commissioned in a quick and hassle-free manner. Our installation service makes things as easy as possible.
Maintenance and repair:
Exceptionally high-quality machines require an exceptionally professional service. That's why it pays to bring in specialists. At ESTOP, we know our systems better than anyone else. But there is much more to a good service than this: we are easy to contact, offer prompt availability and boast motivated employees.
Spare parts:
Do you want to perform any repairs that become necessary yourself? Send us your name, part number and the quantity of the required spare parts. Your order will be processed by us immediately. The prompt delivery of ESTOP genuine spare parts is often crucial to ensure the fast repair of a system. The most popular spare parts are stocked in our factory in China.
Training:
To enable you as a user to work skilfully and safely with ESTOP's milling machine and to evaluate the acquired data in a professional manner, ESTOP offers in-house seminars.
Custom made:
Customized design outside of the typical condition
Service contact:
Do you have a question for our Service Team or would you like to order new machine or spare parts? Professional and easy to contact - you will find the right person to speak to for any matter here.
Certifications
FAQ
FAQ
Q1. What is the payment Terms ?
A1: T/T, 30% initial payment when order ,70% balance payment before shipment; Irrevocable LC at sight. When we receive the advance payment, we will start to make production. When the machine is ready , we will take pictures to you after we got your balance payment. we will send the machine to you.
Q2.How can I choose the most suitable machines ?
A2: Please let us know your machining demand or machine size, we can choose the best model for you, or you can choose the exact model by yourself. You can also send us the products drawing, we will choose the most suitable machines for you.
Q3. What is the package of the machines?
A3: The machines standard packed by iron pallets or Fumigated wood with plywood films.
Q4. What is your trade terms?
A4: FOB, CFR, CIF or others terms are all acceptable.
Q5. What is your minimum order quantity and warranty?
A5: MOQ is one set, and warranty is one year. but we will offer lifetime service for machine.
Q6.When is the delivery time?
A6: We will delivery then within 15-60 working days after received your deposit. If some special machines will be some longer, we will give you the answer accordingly.
Q7: How to ensure the quality?
A7: 1.Firstly we choose best material for the processing.
2.Being and after processing, we will inspect the finished parts.
3.Machine finished, our company QC will test the machine as per customer requests.
Q8: How to deal with the after-sales service?
A8: 1. Technician available for training and installation at customer's company
2. Internet service by sending emails and videos, communicating online or calling
3. One year warranty. During the warranty period, we will sent damage of the machine parts (non-human factors)for free.
Q9: How do we get the training for the machines?
A9: You can send your people to our factory and we will offer training free of charge, or we can send our engineer to your place.
Q10: Where is your factory located?
A10: Our factory is located in Dongguan city and Chongqing city.
Es Top: Professional made the excellent machine.
>>
