Factory Price Quick Lime Plant with Capacity 500 Tons Per Day

Product Description

Factory Price Quick Lime Plant with Capacity 500 Tons Per Day

1.Introduction of lime plant equipment
Our Service and Solution
We can provide technological solutions and complete production equipment for quick lime (active lime) production line.
-Design capacity: 50-700TPD
-We have professional engineer team.
-We have mature experience, and project cases more than 100 till 2011.
-We use the new type, energy saving and environmental system, through which fuel consumption can be reduced by40%, output capacity increased 30%.
Description of Active Lime Production Line:
This active lime production line is a complete line that includes vertical preheater, rotary kiln, grate cooler, air treatment system, raw material conveyor system, finished product conveyor system, raw coal grinding system, and so on. DCS central control system is employed to make concentrated operation management.
The process of lime production line:
Qualified limestone stores in silos and be shipped through the pre-heater by the elevator into the silos which is on the top of the pre-heater. The pre-heater on the top of silos is consisted of top and bottom level meter controllers which control the feeding capacity. Then through the feed tube the limestone is distributed to the indoor compartment of the pre-heater.
Main advantages:
1. Good quality, high output, suitability for the production of large-scale active lime line
2. Stable production& operation, negative pressure through the whole production process, smooth air flow and high safety level.
3. Simple structure, high controllability, easy operation& maintenance.
4. Even fine grade limestone can be calcined, making full use of the mineral resources.
5. Low heat consumption for per unit of product, vertical preheater installed at the end of the kiln can take full advantage of the exhaust for lime preheating and greatly reduces fuel consumption.
6. Making full use of industrial waste gas (such as blast furnace exhaust gas, acetylene tail gas, charcoal blue gas, etc.) as the fuel for lime calcination.
7. Kiln head cover is integrated with the vertical cooler as a whole, through which the construction area is saved, sealing performance is improved, unsystematic gas emission is effectively avoided.
8. The use of pulse bag filter makes it more environmental, emission concentration is 50mg/Nm3, far below the national standard 100mg/Nm3.
Scope of delivery and service:
- Feasibility study
- Creating of basic engineering
- Creating of construction (as-built documentation)
- Delivery of the complete production line equipment
- Delivery of automation system
- Delivery of electrical kits
- Delivery of Lab and test, engineering station for permanent quality monitoring
- Erection the entire plant on the prepared foundations.
- Taking in function (set and run up) of the entire plant.
- Training of customer's operating staff
- Hand over operating manuals and trouble shooting guide line
- One year full replacement warranty
The delivery does not include:
- Delivery and transport from the customer's harbour to the erecting place
- Civil work
- Any building work
- Grounding work
- Entire steel frame work
- Lightning protection
Company information:
Established in 1956, Henan Zhengzhou Ming Machinery Co. Ltd. is an entrenched factory appointed by Ministry of Machine-Building Industry and department of electrical machinery industry of Henan province. After development of over half a century, it has become a comprehensive modernized enterprise which integrates research, design, exploring, manufacturing, selling, installing, debugging and training. Our factory owns fixed assets of more than RMB800 000,000.
Our main products include: rotary kiln, rotary dryer, cooler, ball mill, preheater, conveyor, etc. and complete sets of machinery for cement production line, active lime production line, magnesium production line and ceramic sand production line. We have project cases through every province of China our products have been exported to Russia, Korea, Vietnam, Malaysia, Nepal, Bangladesh, Mexico, Armenia, Africa, South America and other countries and achieved great popularity.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://hnzkjq.en.made-in-china.com
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
