Hot Feed Cold Pin Barrel Rubber Strainer Extruder Machine

Product Description

Product Parameters

Hot Feed Type	XJ-65	XJ-85	XJ-115	XJ-150	XJ-200	XJ-250
Screw Dia.(mm)	65	85	115	150	200	250
L/D	4	4.8	4.8	4.4	4.4	4.5
Screw rotational speed(r/min)	20.27/35.47	27.40/53.72	20~60	27~81	22.4~67.2	19.7~59.1
Motor Power(KW)	7.5	17	30	15.3~55	33.3~100	33.3~100
Dimension L×W×H(mm)	1600×675×1053	2050×735×1275	2770×665×1300	3585×814×1470	4549×1140×1750	4950×1150×1483
Capacity(kg/h)	50~80	62~270	100~350	800	1500~2200	3500
Total weight(Ton)	1.5	2.6	3.3	4.5	7.21	9

Cold Feed Type	XJD-45	XJD-60	XJD-75	XJD-90	XJD-120	XJD-150	XJD-200	XJD-250
Screw Dia.(mm)	45	60	75	90	120	150	200	250
L/D	8-12	8-12	8-14	12-16	12-16	12-18	12-18	12-18
Screw rotational speed(r/min)	~70	~80	60	~60 (55)	~50	~45	~33	~26
Motor Power(KW)	12~22	18.5~22	37-45	45~75	75~110	160~250	220~355	355~450
Dimension L×W×H(mm)	2165x1100x1600	2200x1310x1400	2300x1150x1600	3360x1150x1450	3750x1600x1550	5200x1650x1600	7150x1950x2300	8500x2450x2600
Capacity(kg/h)	15-25	80~150	100-180	250~350	600~800	1000-1500	1600-2500	2800-3500
Total weight(Ton)	1.2	1.8	2.1	3.0	4.2	5.35	9.8	~15

Product Description Features:
1: The material of the screw is made by 38CrMoAlA nitrogen steel with high quality and the surface is nitrogen and its nature is adjusted. The hardness of the surface is HRC60-65 and the depth is 0.5-0.7mm.
2: The material of bush is made by 38CrMoAlA nitrogen steel with high quality and the surface is nitrogen and its nature is adjusted. The hardness of the surface for the inner hole is HRC60-65 and the depth is 0.5-0.7mm.
3: The motor of the equipment is direck current motor with stepless speed regulation. The decelerator is a gear decelerator with cylinder gears of two grades hardness. The precision of transmission is 6 steps.

Product Display::
Company Information:
Qingdao Sea King Machinery Co., Ltd. is located in the west coast of Qingdao,is one of the most famous rubber machinery manufacturers.We have been specializing in rubber machinery for more than 30 years.
The company has passed ISO9001:2008 certification,CE certification,SGS certification,france BV certification.
The main product of our company: Internal mixer, Two roll Mixing mill ,extruding equipments,calendar equipments,Cutting machine,cooling equipment,Vulcanizing equipment,and Reclaimed rubber production line,rubber sheet extrusion line,Motorcycle&bicycle Tube &Tires production line,Conveyor Belt production line, v belt production line,rubber recap equipment and so on. Besides, we also can base on clients' requirement to manufacture and design non-standard rubber machinery.
With the rapid development of our company, Qingdao Sea King industrial Limited was founded. The company has established good commercial relationship with many companies in China by joint venture holding. Products include Rubber Machine ,Raw Rubber Material Rubber Products and so on.
Our company has import-export rights. The products have been exported to many countries and districts around the world, such as America, France, Canada, Dubai,Australia,Peru,Brazil,Ecuador ,SouthAmerican,Southeast Asia, and the Middle East. By the advanced quality and service, our products have gained the praise of domestic and foreign customers.
We strictly follow the policy"to satisfy our clients' need with quality work ,advanced technology,optimized design solution and excellent service".

---
