Product Details
Product Description
Product Description
Product Introduction
This UV wall printer is an industrial control all-in-one machine, using an embedded control panel, no need for a computer. Small and portable, plug and play.
The motor drives the rollers on the china wall printer body to move left and right on the flat ground for printing.
The wall printer china uses UV ink, the color is bright, and when printing on non-absorbent materials (such as metal, wood, glass, ceramic tile), it can be directly printed without pretreatment.
The cost of printing is low, only RMB 2/㎡, economical and practical.Especially suitable for large-format indoor painting.
Product Features
1. The UV wall printer head is detachable to avoid bumping during transportation.
2. The nozzle imported from Japan has the characteristics of fast printing speed, high precision, long life and good stability. The china wall printer is equipped with nozzle protection device to protect the nozzle in all directions.
3. The wall printer china adopts multi-point magnetic suction ink absorber, 14 magnetic suction points not only ensure the air tightness of the ink absorber, but also ensure that the ink absorber is stably absorbed on the head, and can be operated with one hand, which is convenient and quick to install . It comes with one-button cleaning function, no need to manually clean the nozzle.
4. The sensor of the UV wall printer is imported from the USA, the sensing speed reaches millisecond level, the nozzle can expand and contract faster when encountering obstacles, and a metal protective shell is installed to prevent damage to the sensor.
5. The china wall printer machine has a lightweight design, weighs only 39 kg, and can be easily transported. The printing work can be completed by only one person.
6. Train track is optional for outdoor construction which need extra charge.
Application
Applicable Materials
1. Wall Material: Including interior and exterior wall putty wall, latex painted wall, white wall, Imitation porcelain walls, wall clothing, color coating glaze, shell powder, color grain paint, etc.
2.Non-adsorbent Material: glass, ceramic tiles, wood, metals, etc.
Applicable Industries
The UV wall printer is widely used in home decoration, advertising industry, cultural and educational industry, government propaganda, hotel decoration, art experience museum, etc.
Technical Data
Manufacturing State
| In Production
| Flash Spray Test
| Touch
|
Data transmission method
| USB2.0/3.0
| Ink Jet Test
| Touch
|
Sensor
| Double
| Z axis automatic
| Have
|
Length*width*height (host)
| 40cm*50cm*230cm
| Spirit Level
| Have
|
The Fastest Painting Speed
| 8m2/h
| Ultrasonic Sensor
| 2pcs
|
Ink Consumption Per Square
| 6-10ML
| Painted Mode
| Two-Way
|
Nozzle Model
| HD16
| Atlas Type
| External U Disk/Hard Disk
|
Number Of Nozzles
| One
| Automatic tracking
| Have
|
Nozzle Guard
| Have
| Quiet Zone Calibration
| Have
|
Head Ink Tank
| Can Be Split And Transported Separately
| Step Calibration
| Have
|
Motherboard Configuration
| Dual-core CPU, 1GBDDR Memory
| Nozzle Buffer
| Have
|
Highest Painting Accuracy
| 4800DPI
| Spray Distance
| 0.5-2.0cm
|
Painting Direction
| Vertical
| Ink supply method
| Automatic ink supply under negative pressure
|
X Axis Guide
| 2300mm
| Color Processing
| Automatic Color Matching
|
Z Axis Guide
| 170mm
| Painted Medium
| All White Walls
|
Display Screen
| Comes With 12-inch Control Screen
| Integrated Voltage Regulator
| Have
|
X Axis Effective Stroke
| 2000mm
| Laser Positioning
| Have
|
Y Axis Effective Stroke
| Unlimited
| Magnetic Limit
| Have
|
Z Axis Effective Stroke
| 100mm
| UV curing lamp
| Have
|
Total Body Weight
| 39KG
| Nozzle cleaning
| One key automatic
|
Total Track Weight
| 18.8KG
|
Ink Tank Capacity
| 400ML
|
Certification
| Green Environmental Protection Certification,National Standard Testing (GB18582-2001, GBT9756-2001), CE Certification
|
Power Supply
| AC110V（90-132V）/AC220V（180—264V）AC,47-63HZ
|
Power Consumption
| No Load 20W, Generally 75W, Up To 250W
|
Noise
| Standby<20dBA, drawing <50dBA
|
Construction Temperature
| -10°C - 60°C (14°F - 140°F) 10%-80% Relative Humidity, Non-condensing
|
Storage Temperature
| -30℃ - 60℃（-22°F - 140°F）10%-80%Relative Humidity, Non-condensing State
|
Language
| Chinese and English (Customizable)
|
System Platform
| WindowsXP/Win7/Win8/Win10
|
>>
