| model | T36 Flat rail |
| System Configuration | GSK / Optional |
| Maximum rotation diameter on bed ( mm ) | φ 360 |
| Maximum rotation diameter on the pallet ( mm ) | φ 160 |
| X Maximum axis travel ( mm ) | 700 |
| Z Maximum axis travel ( mm ) | 400 |
| Spindle | Mechanical / unit optional |
| Spindle speed ( rpm ) | 50-3000 |
| Spindle end specifications | A2-5 |
| Spindle through hole diameter ( mm ) | Φ 48 |
| Servo main motor power ( KW ) | 4 |
| X Axis servo motor ( Nm ) | 4 |
| Z Axis servo motor ( Nm ) | 4 |
| Clamping method | Hydraulic chuck / chuck optional |
| Cylinder Specifications | 549/649 Optional |
| Tool holder form | Electric knife optional |
| Number of tool positions | 4 |
| Knife square size ( mm ) | 20X20 |
| Guide rail type Z axis | Linear Guide (30 FZS ) |
| Guide rail type X axis | Linear Guide (30 FZS ) |
| Bed type | Flat joint |
| Tailstock power |
- |
| Minimum setting unit ( mm ) | 0.005 |
| Minimum movement ( mm ) | 0.005 |
| Minimum detection volume ( mm ) | 0.005 |
| X Axis rapid movement (m/ min ) | 20 |
| Z Axis rapid movement (m/ min ) | 20 |
| Total weight of machine tool ( kg ) | 1500 |
| Dimensions ( length X Width X Height )( mm ) | 1900x1500x1650
( Height does not include warning lights ) |
(Note: The above configurations can be selected by customers according to their needs)
