Best quality and price AISI ASTM 316 4mm stainless steel wire rope

Product Details

Product Description

Product Description
Best quality and price AISI ASTM 316 4mm stainless steel wire rope
1.Easy to operate, no need to add more flux
2.Saving resources
3.Enviro
Application:
ER316/ER316L: 10Cr-12Ni-2.5Mo (SUS316) used for welding steel, as well as operating Temperature of 600~750 °C chemical, oil refining tube heat exchangers, furnace tubes Peter. Arc stability, weld appearance. Anti-oxidation temperature not less than 870 °C.
ER316LSi: Primarily used for welding of high silicon, low carbon , 18Cr - 12Ni - 2.5Mo steels.
Conform with:AWS:ER316 YB/T:H0Cr19Ni12Mo2 JIS:Y316
AWS:ER316L YB/T:H0Cr19Ni12Mo2 JIS:Y316L
AWS:ER316LSi JIS:Y316LSi
More Details:

Wire Type	Wire Size	Spool Size	Net Weight
MIG Wire	φ0.8~1.6(mm)	D100mm D200mm D300mm D270mm	1kg 5kg 15kg 20kg
TIG Wire	φ1.6~5.0(mm)	1 meter	5kg 10kg

			chemical composition of welding wire(%)
Type	Mechanical Properties or Deposited Metal		C	Si	Mn	Cr	Ni	Mo
	Tensile strengthσb(Mpa)	Elongationδ5(%)
ER316	578	38	0.050	0.60	1.78	19.61	12.50	2.20	-
ER316L	590	40	0.025	0.42	1.91	19.10	12.58	2.57	-
ER316LSi	562	31	0.021	0.77	1.95	19.20	13.45	2.58	-

Please be noted			Welding position
Wire shall be stocked in dry.open the packs just when welding to avoid the wire rust. Before welding please clean out the oil,rust,water etc from the work parts

Packaging & Shipping
5kg/box 1 ton/ pallet
15kgs/spool, 72cartons/pallet
Our Services
1. Free sample is available.
2. The third party inspection is accepted.
3. Bottom price for customers.
4. Best quality is provided.
Company Information
Beall Industry Group is the leading manufacturer and supplier of stainless steel,duplex and super nickle alloy materials with 20 years experience of suplying to a great variety of end users from different fields.
Contact Information:
Shanghai Beall Metal Co.,Ltd
Web:
Tel No: 8621 60530655
Fax No: 8621 51385305
E-mail: sales012 at
Skype: beallindustry012
Att: Alisa Yu

---
