US$8,900.00-12,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Cooling System
Air Cooling
Technical Class
Pulse Laser
Laser Wavelength
Fiber Laser
Laser Classification
Solid Laser
Marking Method
Scanning Marking
Repetition Accuracy
+(-)0.003mm
Certification
Ce, ISO 9001
Repeat Frequency
<(=)30kHz
Transport Package
Plywood
Origin
Guangdong Dongguan
Product Description
Applicable materials:
Main used for all kinds of glass, Charger shell of Samsung and Iphone,earphone, TFT, LCD,
plasma screens, textiles, thin ceramic, Silicon, IC Crystal, Sapphire, polymers, drug, cosmetic, polymer
materials such as wire, bottles (boxes) surface marking, and micro-holes.
Performance characteristics:
UV laser with stable Water-cooling.
UV laser temperature control PID with high precision.
Choose a variety of modes for first pulse suppression,to achieve the best inhibitory effect.
UV laser can offer a variety of different average laser power and pulse width,fit for different
processing requirement.
Technical Parameters:
| Machine model | 3HE-UV3W/5W | 3HE-UV8W |
| Laser wavelength | 355nm |
| Pulse repetition rate | 20-100KHz | 15-100KHz |
| Pulse width | <20ns@30KHz | <25ns@10KHz |
| Average power(W) | 2.0-3.0@30KHz | 4.0-5.0@40KHz | 7.0-8.0@50KHz |
| Average power stability | <±2% over 8 hours |
| Pulse-to pulse instability | <3%rms |
| Spatial mode | TEM00(M2<1.3) |
| Beam divergence | <2mrad(full angle) |
| Beam diameter | 0.6±0.1mm |
| Beam roundness | >90% |
| Pointing stability | <50urad |
| Polarization direction | Horizontal |
| Polarization ratio | 100:1 |
| Cooling method | Air-cooling | Water-cooling |
| Ambient temperature(°C) | 15-30 |
| Storage temperature(°C) | -10-50 |
| Relative humidity | 10%-80%(non-condensing) |
| Warm-up time(mins) | <10 |
| Operating voltage | 90V-260V |
certifications:
Samples show:
Sincerely looking for agents in the world, looking forward to establishing
long-term friendly cooperative relations with foreign trade companies!!
>>
