High Quality 330mesh Polyester Bolting Cloth / Screen Printing Mesh

Product Description

Polyester Screen Printing Mesh / Bolting Cloth
Polyester printing mesh widely used for Graphics printing, Garment printing, Textiles, flat films, Ceramics, Glass, Architectural glass, Cosmetic bottles, Beverage, Advertising, Printed circuit boards, Membrane keypads and overlays ect.

Why we are different? 1. Wide mesh range: 6T- 165T (15mesh to 420mesh) 2. FDA approved 3. Free sample 4. Quick delivery. Meshes in stock, deliver within 7 days. 5. Flexible payment

1. QUALITY is the FIRST !
---- Start from Production
Material yarn from Jintong, Switzerland and Japan, we inspect those yarn arrived (tolerance, tensile strength, physics test etc.).
During production, first we put the warp wires on the beam, drawing the warp wires into heddle and reed. Then our experienced weaver will start weaving mesh according to orders.
Initial survey is taken during and after weaving. Then the heat setting treatment and physical properties inspection will be done before we get tentative finished rolls (normally 60-500 meters rolls).
In the end, after the final inspection, we will cut the mesh into small rolls (20m-50m) according to customer orders.
----- After weaving
Before the screen meshes are dispatched from our factory, we have professional workers to check and test all the details as below, thus to make sure customers get perfect quality.
Testing include:
1> Mesh count inspect
2> Thickness inspect
3> Thread dia & hole inspect
4> Elongation test
5> Tensile test
----- Packing
MAISHI do careful packing, and offer options for the customer to choose as per their favor.

1.Fold the mesh into plastic bag ,then in carton.Suitable for small quantity and have no requirement on the crease.	2.Pack the mesh with paper and plastic bag,then in carton.Suitable for large quantity and the mesh has better surface then folding type.
Paper carton package	Outside pack with weater-proof weaving cloth

2. What mesh SIZES do we have?

Maishi Monofilament Polyester Screen Printing Mesh
model	mesh count	APERTURE	THREAD DIAMETER	OPENING	thickness	INK THROUGH VOLUME THEORETICALLY
	mesh/inch	micron	micron	%	micron	cm 3 /m 2
6-400	15	1300	400	65	780-810	560
10-250	25	700	250	49	508-518	355
12-250	30	610	250	53	495-505	305
15-250	38	467	250	49	489-501	213
18-150	45	410	150	53	255-275	138
21-150	55	330	150	46	260-280	123
24-100	60	316	100	57	136-145	109
24-120	60	302	120	51	230-240	104
30-120	75	213	120	41	235-345	102
32-100	80	212	100	46	145-155	69
36-90	90	183	90	44	160-165	65
39-55	100	195	55	56	88-96	55.0
39-80	100	166	80	43	125-130	59.0
43-80	110	147	80	40.8	127-132	53
48-70	120	135	70	41	108-120	45.5
54-55	135	118	55	47	88-96	44.5
54-64	135	115	64	38.5	95-105	38.9
54-70	135	108	70	34	108-120	40
58-55	145	118	55	38	89-94	39.5
61-64	155	105	64	42	98-107	33
64-45	160	105	48	43	73-82	36.5
64-55	160	98	55	38	85-95	36.1
64-64	160	88	64	30	95-105	30.7
68-55	175	85	55	34	85-90	29
72-48	180	90	48	36	75-84	33.1
77-55	190	81	55	30	88-97	26.6
80-45	200	75	45	36	65-74	27.7
80-48	200	72	48	33	75-84	28.7
90-48	230	56	48	25	77-85	23.5
100-40	250	58	40	33	62-71	21.3
110-40	280	48	40	27	65-71	18.4
110-34	280	54	34	35.5	52-57	20.2
120-34	305	45	34	30.5	52-57	18.4
140-34	355	31	34	19.5	56-62	14.4
150-31	380	36	31	29	43-47	13.1
150-34	380	30	34	20.5	56-62	14.9
165-31	420	31	31	23	52-58	12.88
D (DENIER) =MICRON 9D=31MICRON, 12D=34MICRON, 16D=40MICRON, 22D=48MICRON, 30D=55MICRON; 40D=64MICRON, 50D=70MICRON, 60D=80MICRON, 80D=90MICRON, 100D=100MICRON Notice: Other abnormal specification can be produced if the quantity more than 3000sqm

3. Have STOCK? ---- SURE!
Most of the above mesh sizes are in stock, and could be delivered within 7 days. Thus to make sure our meshes could meet your urgent need.
4. Meshes for application

And other applications include:
CD/DVD Printing,
Ceramic Decorating,
Graphic Screen Printing (Glass Containers, Labels,Large Format UV Graphic, Small Format UV Graphic, Solvent Graphics, Tubes and Cartridges),
Package Printing,
Printed Electronics,
Printing on Glass,
Solar Cell Printing,
Textile Printing,
Tableware.
5. FREE SAMPLE? ----- YES!
MAISHI offer 1-2m free samples for your checking and testing.
Any need for polyester printing mesh, just contact us.

---
