Sunpal Solar Energy System 5kw 10kw off-Grid and Hybrid Solar Systems EU Stock

Product Description

Product Description
8kW Three Phase Solar System Kit with Grade A Lithium Battery
We offer ready-to-use complete solar energy system to meet household needs, ensuring excellent reliability and efficiency.A Single-phase system with 8 kW power capacity and 10 kWh solar energy storage capacity is suitable for covering the needs of larger households, office buildings, small-scale manufacturing, or guest houses. It can power both indoor and outdoor lighting,washing machines, dryers, multiple televisions, 2 refrigerators, computers, water pumps, and summer air conditioning. For the winter season, it may be necessary to add a generator to the system if you are not connected to the grid.
Application
Advantages of a 8 kW Hybrid Three-Phase Solar SystemA 8 kW hybrid solar system is a standalone electricity generation system that combines solar panels, inverters, batteries, and
other components. This system is designed to power your home with clean energy from the sun while allowing you to store excess
energy for later use.
* Reducing electricity bills
* Uninterrupted power supply
* Environmentally friendly solution
* System flexibility tailored to your specific needs
What does the solar kit include?The solar system kit includes all necessary accompanying elements for installing the solar system: Mounting Structure - supporting framework for solar panel installation, including mounting profiles, accessories, consumables, and fasteners; AC/DC Wiring-cabling for both AC and DC connections, including solar cables, DC connectors, and power cables; Control Panel - containing protective and switching equipment for managing the system.

8kW Hybrid Solar System Components
Item	Model	Description	Quantity
Solar Panel	SP585M-72H	Power: 585WWeight: 31.5KGSize: 2279 × 1134 × 30mm	14 Pieces
Hybrid Solar Inverter	SUN-8K-SG01LP1-EU	Power:8000WMPPT Range: 150V-425VOutput Voltage:230Vac (Single phase);50/60Hz	1 Piece
Lithium Battery	SP-BAT-W10.24Da	Capacity: 51.2V 200ah 10.24 kWh	1 Piece
Mounting Structure	Sunpal PV Mounting System	Customized Product Based On Installation Roof/Ground	1 Set
PV Cables	PV1-F Cable	4mm2/6mm2	100 Meter
MC4 Connector	PV004-EN	Rated Voltage: 1000V	7 Pairs
PV Installation Tools	Solar PV Tools	Wire Cable Cutter & Stripper,MC3 MC4 CrimperMC4 Connectors AssemblyDisassembly Tool	1 Set
Smart Meter	DDSU666	AC voltage: 176-264V	1 Piece

Estimated Savings from Solar Panel Systems (25 Year Projection)

System Size (kW)	Estimated Annual Savings	Estimated 25-Year Savings
5 kW	$900 - $1,500	$22,500 - $37,500
8 kW	$1200 - $2,000	$30,000- $50,000
10 kW	$1500 - $2,500	$37,500 - $62,500

Products Images Topcon N type Bifacial 585W* 30 years Warranty
* Positive power tolerance (0~+5W) guaranteed (up to 22.53%)
* Slower power degradation 0.40% year 2-30
* Solid PID resistance ensured by solar cell process optimization and careful module BOM
selection
* Reduced resistive loss with lower operating current
* Higher energy yield with lower operating temperature8kW Hybrid Solar Inverter* Max. 10 pcs parallel for on-grid and off-grid
operation; Support multiple batteries parallel
* Max. charging/discharging current of 240A
* 48V low voltage battery
* 6 time periods for battery charging/discharging
Monitoring System* Open station supports one-click installation and registration Problem support one-click dispatch and navigation Safe operation,
traceable logs, etc
* Support full lifecycle data storage to ensure data security and reliabilityWall Mounted LiFePo4 Battery* New wall mount design.* Max.15pcs in parallel to extend capacity.
* Quick plug in +/- and parallel connection.
* SOC, Battery status.
* Lithium iron phosphate (LFP) cell. PV Mounting System* Mounting Rail & Rail Splice Kit: AI6005 & SUS304 Bolt.
* Mid & End Clamps: 35,40,45,50mm
* L Foot Asphalt Shingle Moount & Hanger Bolt Optional
* Cable Clip & Tie Optional
* Ground Clip & Lugs OptionalDC Cable & MC4 Connector* Cross Section: 4mm2, 6mm2 OptionalRated * Voltage:600VDC(UL)/1000VDC(TUV)
* Rated Current: 55A,70A
* Colors: Black For STD, Red Optional.
* Lifetime:≤25 Years DC & AC Disconnect Switch* IP Rating: IP66
* Rated Voltage: 1000VDC
* Connection Type: M20,M25,MC4
* Rated Current: 16A,20ASmart Meter* Local LCD display, RS485 communication
* Adopting the standard DIN35mm din rail mounting
* Small volume, easy installation and easy communication
* Positive and reverse active power, four quadrant reactive power metering PV Tools* Wire Cable Cutter & Stripper,
* MC3 MC4 Crimper
* MC4 Connectors Assembly
* Disassembly Tool Factory Details
As a world-class solar products manufacturer, Sunpal specializes in the research, development, production, and sales of solar PV products, mainly in charge of solar panels, solar batteries, solar inverter and a complete solar system.
Sunpal is accredited as Batch I Smart Manufacturing Plant by Jiangsu Government, the Witness Laboratory Accreditation Certificate (WMTC) by CE.ISO Laboratory Certificate by TUV SUD. Sunpal focused on research and manufacture of solar battery since the year 2005, we have exported our various kinds of battery to 86 countries and won a good reputation in quality. With over 10 years of development, Sunpal now has factory area covering 150,000 square meters, with 600 experienced employees.
