Long Life PVC Blade Type Pulverizing Mill

Product Description

Application of Our Plastic Turbo Blades Type Pulverizer
This pulverizer is high speed, turbo-type grinders for the processing of medium hard, impact resistant and friable materials, for example PVC,PS and so on.
1. Compared with similar grinders, its output is greatly improved (increased by 20%-50%) under the same power. It is energy-saving.
2. The dust collector is added to effectively reduce dust pollution.
3. The discharging of the main fan reduces labors intensity of operating workers.
4. The door cover of the host can be opened for convenience of maintenance and replacement of cutters.
5. Wind and water cooling system are adopted to decrease the working temperature inside the machine body, so the grinded material uneasy for denaturalization and also conducive to grind heat sensitivity plastics.For example, the part of PE and ABS can be grinded by this machine.
6. The powder mesh is adjustable (20-100 mesh).

Why Choose from Lanhang

1. Since1992, with more than 20 years' professional experience
2. Overseas service center available (in Europe, Japan, Dubai, etc.)
3. International CE, SGS, IAF, CNAS certification
4. National high-tech enterprise / products
5. Various National Patent for Inventions Letters for rubber & plastic machinery
6. ISO9001:2008 management

Main Parameters:

Item	SMF400	SMF500	SMF600	SMF800
Grinding chamber diameter	390	483	583	783
Main motor power	30KW	37kw	55kw	75kw
Capacity (kg/h)	50-100kg/h	120-280	180-450	280-850
Finished product size (mesh)	15-120	15-120	15-120	15-120

Note: Capacity depends on the material kinds, size of raw material, and the finess of the finishedgrinding materials.Usually, the original diameter of the raw material ranges from 5 to 8 mm.

Application of Our Plastic Disc Type Pulverizer
Disc-type pulverizer series with the disc diameter from 300mm to 800mm.This pulverizer is high speed, precision grinders for the processing of medium hard, impact resistant and friable materials, for example PE,PVC,PP,ABS,PA,EVA,PET,PS,PPS,EPS,PC,Foam,Cow leather and so on.

Advantages:
Save and simple adjustment of cutting gap
Low drive power and High throughput
Innovative efficient design
Easy to maintain and control
Wide range of accessories
Automatically regrinding coarse powder
Dual cooling system

Applications:
One of the main usage for this plastic pulverizer is the pulverization of PE for rotomolding applications. In this process, a screening machine is necessary to ensure the right output size, other applications are the working in line with a shredder and crusher to have a balance and efficient system to handle in house production waste.

Why Choose from Lanhang

1. Since1992, with more than 20 years' professional experience
2. Overseas service center available (in Europe, Japan, Dubai, etc.)
3. International CE, SGS, IAF, CNAS certification
4. National high-tech enterprise / products
5. Various National Patent for Inventions Letters for rubber & plastic machinery
6. ISO9001:2008 management

Main Parameters:

Model No.	MF-300	MF-400	MF-500	MF-600	MF-800
Disc Dia. (mm)	Ø 300	Ø400	Ø 500	Ø 600	Ø 800
Grinding chamber dia. (mm)	Ø 250	Ø 350	Ø 450	Ø 550	Ø750
Main motor power (kw)	7.5-11	22-30	37-45	45-55	75-90
Cooling way	Water cooling
Fan power(kw)	2.2	3	4	5.5	11.5
Vibrosieve power(kw)	0.55	0.75	1.1	1.5	2.2
Capacity (kg/h)	50-120	120-200	180-400	260-600	550-950
Machine size (mm)	1500×1100×3200	1700×1500×3400	1800×1600×3600	1900×1700×3800	2300×1900×4200
Machine weight(kg)	1100	1200	1600	2200	3500

Note: Capacity depends on the material kinds, size of raw material, and the finess of the finishedgrinding materials.Usually, the original diameter of the raw material ranges from 5 to 8 mm.

---
