Universal Cylindrical Grinding Machine

Product Description

Universal Cylindrical Grinding Machine
Cylindrical Grinding Machine
Universal Cylindrical Grinding Machine

Model		Unit	G-200	UG-200	G-320	UG-320
General capacity
Distance between centers		mm	500/750	500/750	1000/1500/2000/3000	1000/1500/2000/3000
Center height		mm	135	135	180	180
Dia. Ground (O.D)		mm	5-200	5-200	8-320	8-320
Dia. Ground (I.D)		mm	-	25-100	-	30-100
Max. length ground (O.D)		mm	500/750	500/750	1000/1500/2000/3000	1000/1500/2000/3000
Max. length ground (I.D)		mm	-	100	-	125
Max weight of work piece		Kg	-	100	150	150
Workhead
Swiveling angle		°	-	+90 °	-	+90 °
Center taper (MT)		MT	4	4	5	4
Spindle speed		r/min	50HZ:25-380	50HZ:25-380	26,52,90,130,180,260	50HZ:25-220
Wheel head
Wheel spindle speed		rpm	1335	1670	110	1670
Wheelhead rapid travel		mm	50	50	50	50
Max. travel		mm	205	205	235	246
Swiveling angle		°	-	±30°	-	±30°
Wheel size(ODxWxID)		mm	500x50x203	400x50x203	600x63x305	400x50x203
Peripheral speed		m/s	35	35	35	35
Internal grinding device
Spindle speed		r/min	-	10000	-	10000
Wheel size		mm	-	Max:35x25x10, Min:17x20x6	-	Max:50x25x13, Min:17x20x6
Table
Hand feed per. rev		mm	6	6	6	6
Max. swiveling angle	clockwise	°	3 °	3 °	3 °(1000/1500)/2 °(2000/3000)
	anticlockwise	°	9 °(500)/8 °(750)		7°(1000)/6°(1500)/5°(2000)/3°(3000)
Longitudinal feed speed		m/min	0.1-4	0.1-4	0.1-4	0.1-4
Tailstock
Center tape (MT)		MT	4	4	4	4
Quill travel		mm	30	30	30	30
Motor
Wheelhead motor power		kw	5.5	4	11	5.5
Internal grinding		kw	-	1.1	-	1.1
Workhead motor power		kw	0.75	0.75	0.75/1.5	1.5
Machine
Gross weight		T.	4/4.2	4.1/4.3	5.3/6.1/7.9/9.9
Packing dimension		cm	260/300x203x205	260/300x203x205	322/422/540/739x200x2050

Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

---
