Wheel/Rolling/Roller/Slewing/Auto/Needle Bearing/Pillow Block/NSK/FAG/NTN/ Ball/Hybrid Ceramic Ball Bearings 606/607/W608/609/624/625/626/627/628/629/2z/2rsh/C3

Product Description

608-2Z Deep groove ball bearing
Deep groove ball bearing 60..-2Z,
single row,
shields,
steel sheet metal cage

608-2Z
Main Dimensions & Performance Data
d	Bore diameter	8mm
D	Outside diameter	22 mm
B	Width	7mm
Cr	Basic dynamic load rating, radial	3297 N
C0r	Basic static load rating, radial	1368 N
Cur	Fatigue load limit, radial	74 N
nG	Limiting speed	40000 r/min
nϑr	Reference speed	31500 r/min
Weight		0.012 kg
D2	Caliber diameter outer ring	19.03 mm
d2	Shoulder diameter inner ring	10.5mm
da min	Minimum diameter shaft shoulder	10mm
Da max	Maximum diameter of housing shoulder	20mm
ra max	Maximum fillet radius	0.3 mm
f0	Calculation factor	12.4
Other Details
1) Package: wooden/box/carton packaging

RTB bearing manufacture a full range of deep groove ball bearings. These bearings are the most common type and are used in a wide variety of applications.Miniature and instrument ball bearings can be divided into two basic types, deep groove and angular contact.
REET bearing company specializes in the production of high temperature endurance bearing series and ceramic ball bearings.Deep groove ball bearings are widely used in the industrial field and are highly valued by many countries.

Model		Inner diameter(mm)	Outer diameter(mm)	Thickness(mm)	Net weight(kg)	Cage
623-2Z	80023	3	10	4		steel
623-RS	160023	3	10	4		steel
623-2RS	180023	3	10	4		steel
624	24	4	13	5	0.003	steel
624-Z	60024	4	13	5		steel
624-2Z	80024	4	13	5		steel
624-RS	160024	4	13	5		steel
624-2RS	180024	4	13	5		steel
625	25	5	16	5	0.005	steel
625-Z	60025	5	16	5		steel
625-2Z	80025	5	16	5		steel
625-RS	160025	5	16	5		steel
625-2RS	180025	5	16	5		steel
626	26	6	19	6	0.008	steel
626-Z	60026	6	19	6		steel
626-2Z	80026	6	19	6		steel
626-RS	160026	6	19	6		steel
626-2RS	180026	6	19	6		steel
627	27	7	22	7	0.014	steel
627-Z	60027	7	22	7		steel
627-2Z	80027	7	22	7		steel
627-RS	160027	7	22	7		steel
627-2RS	180027	7	22	7		steel
628	28	8	24	8	0.016	steel
628-Z	60028	8	24	8		steel
628-2Z	80028	8	24	8		steel
628-RS	160028	8	24	8		steel
628-2RS	180028	8	24	8		steel
629	29	9	26	8	0.019	steel

TIANJIN REET BEARING.CO.,LTD is a professional bearing manufacturer and exporter.
We have a wealth of technical.All producing processes are finished in our manufactory. As an ISO9001:2000 certified manufacturer,we will solve various problems in application and use of our bearings.
Our company is an authorized distributor of FAG, INA, TIMKEN and other world brand bearings.Our company has the right to self-export bearings and launches its own brand RTB.
Our bearing had been exported to more than twenty countries worldwide and are warmly welcomed.
We're looking forward to your order.
FAQ 1.Is the company a production factory or a trading company? TIANJIN REET BEARING CO.,LTD is a manufacturing enterprise focusing on bearings and integrating research, production and sales.
2.How many the MOQ of your company? Depending on the size of the bearing, the MOQ is variable, if you are interested, you can contact me for a quote.
3.Does the company accept OEM or customized bearings?
In addition to standard products, we also supply non-standard and modified standard products for special application. Meanwhile, we provide OEM service.
4.Can the company provide free samples?
We can provide samples for free. You only need to provide shipping.
5.What are the company's delivery terms?
We can accept EXW,FOB,CFR,CIF,etc. You can choose the one which is the most convenient cost effective for you.

---
