| Projection Specification | |
| Projection Technology | DLP(0.2"DMD) |
| Projection Light | RGB LED OSRAM Q6 |
| Light Life | Up to 20,000 hours |
| Light Luminance | 150 Lumens |
| Light Type | LED |
| Standard Resolution | WVGA 854*480 |
| Projection Area | 40-300 inch |
| Contrast | 500:1 |
| Projection Ratio | 1.4:1(31 inch@1M) |
| Distortion | <1.5% |
| Luminance Uniformity | >85% |
| Projection Distance | 1-8m |
| Aspect Ratio | 16:9 |
| Focus mode | Manual focus |
| Keystone Correction | Vertical ±40 degree,Horizontal ±45 degree,Multi angle adjustment |
| Projector Character | Interaction |
| Projection Mode | Front Projection |
| Offset function | 100% |
| 3D | YES |
| System Parameters | |
| Screen Mirror | Airplay/MiraCast |
| OS | Android 9.0 |
| CPU | T972(Amlogic) |
| Basic Frequency | Quad Core ARM Cortex-A55 CPU |
| GPU | ARM Mali-G31 MP2 GPU |
| Buffer Memory | 2GB/4GB LPDDR4 |
| Memory | 16GB/32GB EMMC |
| WIFI | 2.4G/5G |
| Bluetooth | BT 4.2 |
| Basic parameters | |
| Built-in Battery | 9000mAh=2*4500mAh (4500mAh 7.4V 33.3Wh) |
| Usage time | work for about 2 hours |
| Video Support(up to 4K) | VP9-10,H.265,H.264,MPEG-4,WMV/VC-1,MPEG-2,MPEG-1,RealVideo 8/9/10 etc. |
| Audio Support | MP3,WMA,MP2,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WAV |
| Image Support | Supports variety of image formats browsing (jpg, png, bmp etc.) |
| Extended Storage | Support TF Card and Hard Disk |
| Remote Control | Support IR and 2.4G wireless control |
| Built-in speaker | one 2W speaker |
| Light machine Consumption | 11W |
| Whole Power Consumption | 16W |
| Power Performance | AC100-240V,50/60Hz, DC 12V 3A |
| Interface | 1*TF Card: Max 32GB |
| 1*HDMI: HDMI Input 1.4 | |
| 2*USB: USB 2.0 Support USB hard disk data read | |
| 1*Earphone: Audio output, 3.5mm joint (can connect with earphone or speaker box) | |
| Ethernet:100M | |
| 1* DC input: DC 12V 3A | |
| Package | |
| Colour | Gray/Black + metal frame |
| Net weight | 468g |
| Dimension | 16x9.8x2.8cm |
| Gift Box weight | 994g |
| Gift Box Size | 20.6x12.9x8.4cm |
| Carton box weight | 10.4kg(10pcs) 20.6kg (20pcs) |
| Carton box size | 46x22x28cm (10pcs) 44.5x43x28cm (20pcs) |
