High Frequency for Furniture Door Bending Machine Plywood Machine Hot Press

Product Description

HF/RF High Frequency Bent Wood Press

1.High frequency wood bending press applies high frequency generator to hydraulic press, by mould and electrode.
2.It transfers the high frequency power to the work piece to achieve the function of fast gluing and forming.
3.Be suitable for: bent plywood chair, bent or arc plywood for the furniture or bed or other bent plywood products like cloth hanger or surface of musical instrument.
Character
HF/RF High Frequency Bent Wood Press
1. Fast and uniformly heating.
2. Bending shape is stable, not easy to change delamination.
3. High frequency power is a selectively heating power, it concentrates only on water or glue, wood not consume High Frequency power, so HF heating is effective and power saving.
4. Wooden or MDF mould used, much ecnomic than metal mould if shape is frequently changed.

Basic Parameter

Mode	YX80-SA	YX150-SA
HF Generator	20kW, 2 Output	30kW, 2 Output
Press Working Size	1600*800mm	2500*1300mm
Cylinder	80T(2PCS)	150T(2PCS)
Stroke of cylinder	600mm	600mm
Control	Automatic	Automatic
Power of Hydraulic	7.5kW	7.5kW
Opening of Plate	1200mm	1200mm
Over size	2300*800*2200mm	2900*1300*2200mm

ABOUT SAGA :

Saga Machinery Co,. Ltd specializes in developing, designing and producing High Frequency Machineries. We are a professional HF Machinery supplier in China. Our products cover with High Frequency Hot Press, High Frequency Generator,High Frequency Curved Plywood Press, High Frequency Vacuum Wood Dryer, High Frequency Guitar Machine, Wood Kiln, High Frequency Belt Conveyor, etc
Detail Pictures
FAQ
1. who are we? We are based in Hebei, China, start from 2010,sell to Eastern Asia,Mid East,Domestic Market,Africa,Southeast Asia,South Asia,Southern Europe,Northern Europe,Oceania,Eastern Europe,South America,North America. There are total about 51-100 people in our office. 2. how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3.what can you buy from us? high frequency generator,high frequency vacuum wood dryer,high frequency edge gluer,high frequency plywood curved press,high frequency frame assembly machine 4. why should you buy from us not from other suppliers? We are first one which can make full-automatic control system for High frequency vacuum wood drying . 5. what services can we provide? Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery; Accepted Payment Currency:USD,EUR,CNY; Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Escrow; 6. Provide customized machine Yes or NO?
R: Yes. We have professional designers and engineers to supply customized machines.
7. Q: What is payment terms?
R: 30%T/T in advance, the balance paid before shipment after inspection.
8. Q: What is the warranty time?
R: One year.

---
