Metal Universal Vertical Turret Knee Type Milling Machine X6336z

Product Description

1. General datas	X6336Z
Max drilling dia.	φ30mm(cast iron,manual)
Max vertical milling dia.	φ25 mm
Worktable dimensions	1700 x 400 mm
Longitudinal travel	1300 mm
Transversal travel	340 mm
Vertical travel	450 mm
Max load over worktable	400 kg
2. Vertical spindle
Spindle taper	ISO 40
Spindle speed number	8
Spindle speed range	108 ~ 2400 rpm
Spindle travel	127 mm
Distance between spindle and surface of column	200 ~ 550 mm
Distance between spindle and surface table	100 ~ 440 mm
Headstock swivel angle	± 90º
Torpedo travel curse	580mm
With dovetail guide width	320mm
3. Horizontal spindle
Spindle taper	ISO 50
Spindle speed number	12
Spindle speed range	70 ~ 2160 rpm
Distance between spindle and surface table	80 ~ 480 mm
4. Motors
Vertical motor power	5 hp
Horizontal motor power	5,4 hp
Feed motor power (longitudinal and transversal)	0.75 hp
Feed motor power (vertical)	1 hp
5. Machine dimensions
Length	2220 mm
Width	1800 mm
Height	2450 mm
Net weight	2350 kg
6. Diameter Screw
X Axis	32MM
Y Axis	32MM
Z Axis	44MM

X6336Z Universal Milling machine
The machine is with gear driven milling head, and the spindle can be automatic feed.
The machine is with X,Y mechanical feed, Z lifting and lowering motor.
The machine is with operation panel which is convenient for the operator to use.
The ram can be movable forward and backward.
The machine head can swivel 45 degrees.
The machine can be equipped with options DRO, spindle protection, etc.
OEM FEATURES:
Conventional milling machine without clp or cnc control, with transmission by gears lubricated in oil, vertical head with 8 variable speeds changed by positioning of levers rotations between 108 to 2400rpm with ISO-40 tool cone, horizontal spindle with transmission by gears lubricated in oil with 12 variable speeds shifted by positioning levers with rotations between 72 to 2160rpm with ISO-50 tool cone, table with dimensions 400mm x 1700mm and NR12 protection fairing with interlock key, Axes travel X 1300mm, Y 340mm, Z 450mm, X spindle of the table diameter 32mm pitch 4mm, Y spindle of the table diameter 32mm pitch 5mm, Z spindle table diameter 44mm pitch 7mm, driven by electric motor, torpedo with 580mm stroke, vertical motor power 2.2kw, horizontal motor power 4kw , vertical column with square rail of guide width 320mm. Electrical controls installed on a panel with an articulated arm on the left side of the machine.

---
