| US$17,000.00 | 1 Piece (MOQ) |
| Engine | ||
| Make | Isuz-u | |
| Model | CC-4JG1 | |
| Net Power | 52 hp | 39 kw |
| Power Measured @ | 2100 rpm | |
| Displacement | 186.7 cu in | 3.1 L |
| Torque Measured @ | 1800 rpm | |
| Max Torque | 141.6 lb ft | 192 Nm |
| Number of Cylinders | 4 | |
| Operational | ||
| Operating Weight | 15256 lb | 6920 kg |
| Fuel Capacity | 35.7 gal | 135 L |
| Cooling System Fluid Capacity | 2.5 gal | 9.5 L |
| Hydrauilc System Fluid Capacity | 26.4 gal | 100 L |
| Engine Oil Capacity | 3.2 gal | 12 L |
| Operating Voltage | 24 V | |
| Alternator Supplied Amperage | amps | |
| Hydraulic System Relief Valve Pressure | 4554.2 psi | 31400 kPa |
| Hydraulic Pump Flow Capacity | 47.2 gal/min | 178.5 L/min |
| Swing Mechanism | ||
| Swing Speed | 11.3 rpm | |
| Undercarriage | ||
| Number of Shoes per Side | 38 | |
| Shoe Size | 17.7 in | 450 mm |
| Number of Carrier Rollers per Side | 1 | |
| Number of Track Rollers per Side | 5 | |
| Ground Pressure | 4.6 psi | 32 kPa |
| Max Travel Speed | 3.1 mph | 5 km/h |
| Track Gauge | 5.7 ft in | 1750 mm |
| Buckets | ||
| Reference Bucket Capacity | 0.37 yd3 | 0.28 m3 |
| Minimum Bucket Capacity | 0.17 yd3 | 0.13 m3 |
| Maximum Bucket Capacity | 0.43 yd3 | 0.33 m3 |
