| US$55.00-60.00 | 100 Pieces (MOQ) |
| Camera Module No. | KLT-USB-0485 V1 |
| Resolution | 2.1MP |
| Image Sensor | AR0230 |
| Sensor Type | 1/2.7" |
| Pixel Size | 3.0 um x 3.0 um |
| EFL | 3.00 mm |
| F.NO | 2.40 |
| Pixel | 1920 x 1080 |
| View Angle | 96°(DFOV) |
| Lens Dimensions | 13.40 x 13.40 x 23.60 mm |
| Module Type | Fixed Focus |
| Lens Model | KLT-LENS-0485 V1 |
| Interface | USB 2.0 |
| Output Format | MJPG / YUV2 |
| Auto Control | Saturation, Contrast, Acutance White Balance, Exposure |
| Audio | Digital Microphone, Single, Dual Channel |
| Input Voltage | DC 5V |
| Working Current | Max 500mA |
| PCB Size | 38 x 38 mm / 32 x 32 mm |
| System Compatibility | Windows XP (SP2, SP3), Vista, 7, 8, 10, 11 Android, Mac OS, Linux or OS with UVC Driver Raspberry Pi by USB Port |
| Software for USB Camera | AMCAP, Webcam Viewer, V4L2 Controls Contacam, VLC Player, MotionEye OS iSpy, ZoneMider, Yawcam |
| Lens Type | 650nm IR Cut |
| Operating Temperature | -30°C to +85°C |
| USB Cable | KLT-Cable-U015 |
| AR0220AT AR0237SR AR0130CS AR0132AT AR0134CS KLT KaiLapTech Camera Module |
| AR0135AT AR0135CS AR0138AT AR0140AAT AR0140CS KLT KaiLapTech Camera Module |
| AR0141CS AR0144AT AR0144CS AR0221 AR0230AT KLT KaiLapTech Camera Module |
| AR0230CS AR0231AT AR0233AT AR0234AT AR0234CS KLT KaiLapTech Camera Module |
| AR0237 AR0237 RGB-IR AR0237AT AR0238 AR0239 KLT KaiLapTech Camera Module |
| AR0261 AR0330 AR0330CM AR0331 AR0430 AR0431 KLT KaiLapTech Camera Module |
| AR0521 AR0522 AR082AT AR1011 AR1335 AR1337 KLT KaiLapTech Camera Module |
| AR1630 AR1820HS ARX3A0 ARX550AT AS0140AT KLT KaiLapTech Camera Module |
| AS0142AT AS0260 ASX340AT ASX340DS ASX342AT KLT KaiLapTech Camera Module |
| ASX344AT ASX350AT IBIS4-6600 LUPA130-2 LUPA300 KLT KaiLapTech Camera Module |
| LUPA3000 MT9J003 MT9M001 MT9M021 MT9M024 KLT KaiLapTech Camera Module |
| MT9M034 MT9M114 MT9P001 MT9P006 MT9P031 KLT KaiLapTech Camera Module |
| MT9V022 MT9V023 MT0V024 MT9V034 MT9V115 KLT KaiLapTech Camera Module |
| MT9V124 MT9V126 MT9V127 MT9V128 PYTHON1300 KLT KaiLapTech Camera Module |
| PYTHON16K PYTHON2000 PYTHON25K PYTHON300 KLT KaiLapTech Camera Module |
| PYTHON480 PYTHON500 VITA12K VITA1300 VITA16K KLT KaiLapTech Camera Module |
| VITA2000 VITA5000 XGS 12000 SGX 16000 XGS 2000 KLT KaiLapTech Camera Module |
| XGS 20000 XGS 3000 XGS 30000 XGS 32000 KLT KaiLapTech Camera Module |
| XGS 45000 XGS 5000 XGS 8000 XGS 9400 KLT KaiLapTech Camera Module |
| GC13053 GC8054 GC8034 GC13603P GC8603 GC9702 KLT KaiLapTech Camera Module |
