| US$50,000.00-90,000.00 | 1 Piece (MOQ) |
Machine data/model | Unit | VMC-850 | VMC-1060 | VMC-1270 | VMC-1370 | VMC-1580 | VMC-1690 | VMC-1890 | |
| X/Y/Zaxis travel | mm | 800/500/550 | 1000/600/600 | 1200/700/600 | 1300/700/650 | 1500/800/700 | 1600/900/680 | 1800/900/680 | |
| Travel | Distancefrom spindlenoseto tablesurface | mm | 105-655 | 180-780 | 150-750 | 150-800 | 170-870 | 160-840 | 160-840 |
| Distancefromspindlecenterto cumngudesurface | mm | 550 | 600 | 785 | 785 | 810 | 950 | 950 | |
Workbench | Workbench size | mm | 1050×500 | 1300×600 | 1360×700 | 1400×700 | 1700×800 | 1800×900 | 2000×900 |
| Workbench load-bearing | kg | 600 | 1000 | 1200 | 1200 | 1600 | 1600 | 1800 | |
| T-slot(numberofslots-sizexspacing) | mm | 5-18×90 | 5-18×120 | 5-18×152.5 | 5-18×152.5 | 5-22×135 | 5-22×165 | 5-22×165 | |
Spindle | Spindletaper specifications | BT40 | BT40 | BT40/BT50 | BT50 | BT50 | BT50 | BT50 | |
| Spindlespeed(Optional) | rpm | 8000/10000/12000 | 8000/10000 | 8000/10000 | 6000 | 6000 | 6000 | ||
| Spindle motor power | kw | 7.5 | 11 | 15 | 15 | 18.5 | 18.5 | 18.5 | |
| Three-axis parameters | Three-axis motor power(XY/Z) | kw | 3.0/3.0/3.0 | 3.0/3.0/3.0 | 3.0/3.0/3.0 | 3.0/3.0/3.0 | 4.0/4.0/4.0 | 4.0/4.0/4.0 | 4.0/4.0/4.0 |
| X/Y/Zaxis rapid moving speed | m/min | 18/18/16 | 18/18/16 | 18/18/16 | 18/18/16 | 18/18/16 | 18/18/16 | 18/18/16 | |
| Cutting feed speed | mm/min | 0-10000 | 0-10000 | 0-10000 | 0-10000 | 0-10000 | 0-10000 | 0-10000 | |
| Position | Position accuracy | mm | ±0.005 | ±0.005 | ±0.005 | ±0.005 | ±0.005 | ±0.005 | ±0.005 |
| Repeated position accuracy | mm | ±0.003 | ±0.003 | ±0.003 | ±0.003 | ±0.003 | ±0.003 | ±0.003 | |
Magazine | Magazine capacity | Put | 24 | 24 | 24 | 24 | 24 | 24 | 24 |
| The maximum weight of cutter | kg | 7 | 7 | 18 | 18 | 18 | 18 | 18 | |
| The maximum length of cutter | mm | 300 | 300 | 300 | 300 | 300 | 300 | 300 | |
| Cutter diameter(full/interspace) | mm | 80/150 | 80/150 | 112/200 | 112/200 | 112/200 | 112/200 | 112/200 | |
| Magazine form | Disc type | ||||||||
Other | Pressure demand | Kg/cm² | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 |
| Machine weight | Kg | 5500 | 7500 | 10500 | 11000 | 13500 | 13500 | 15500 | |
| Machine size length x width x height) | m | 28×26×2.85 | 3.3×29×3.05 | 3.5×3.0×3.2 | 3.6×3.1×3.3 | 3.9×3.3×3.5 | 4.1×3.5×3.55 | 4.4×3.5×3.55 | |
