High Speed Paper Cup /Paper Bowl /Paper Cup Sleeve Machine (JBZ-D)

Product Description

1. Equipment Name: Paper cup sleeve machine
2. Description:
Model JBZ-D Paper Ripple Cup Sleeve Wrapping and Forming machine is a advanced machine developed on the JBZ-D double walls paper cup machine. In this machine, the out sleeve layer are corrugated paper. The difference between theJBZ-S30 and JBZ-Dmodel sleeve forming machines: The sleeve feeding device is different, In the JBZ-S30 Corrugated out-sleeve forming machine, the feeding device is a mechanical hand.
About the out-sleeve corrugate layer: The inside layer ( face the inner cup layer) is light PE coated paper (100GSM for example); The outside layer is raw paper(printed); It is easy to finish the corrugated paper on a corrugating machine.
3. Technical Specification:
JBZ-D Paper Cup/Bowl Sleeve Machine
Technical Specification:
A. HS. Code: 8441309000
B. Paper Cup Size: 5-16oz cup / 20--50oz bowl (mold exchangeable);
C. Raw Material: PE paper, Varnishing Printed paper, or other film coated paper (can be sealed by ultrasonic);
D. Suitable paper weight: 170-450GSM (Recommend 250-300 GSM);
E. Rated Productivity: 40---50 PCS / minute;
F. Total Power: 4 KW;
G. Power Source: 380V 50Hz or other required;
H. Total Weight: 1000 Kg;
I. Package Size (L x W x H): 2450 X 1200 X 2000 mm

---
