4CH 720P HDD mobile DVR support 3G/4G /GPS used for Car/bus/taxi
Key Features: Industrial level design; Advanced audio/video compression technology; 4-channel video input,1ch audio input; ASF standard file format; Local PTZ control; Data redundant storage technology; Patent UPS power-off protection design; Fast startup; Optional function: Bi-directional voice communication, telephone dialing, disk pre-heating; Central management software provided for optional; Support intercom function; Support I/O alarm, over speed alarm, g-sensor alarm, video lose alarm, motion detection alarm; Support broadcast voice; Support 2TB HDD&max 256G SD card.
CPU
| Hi silicon
|
Basic functions
| REC,PLAYBACK,ALARM,VGA,USB,IR,SD,TV-OUT,etc.
|
functions
| GPS 4G WIFI for optional
|
Power Supply
| Car battery(For mobile monitoring)/Power adapter(For other applications)
|
Power input
| (Standard power input:DC12V~DC24V, ultimate input: DC8V~DC38V)
|
Power output
| DC12V/3A
| Provide power for cameras,with built in re-settable fuses.
|
Working Current
| 250~380 ±10 mA (the reference voltage is:DC24V)
|
Working temperature
| - 10°C~ + 50°C (ultimate working temperature: - 20°C~ + 60 °C)
|
Storage interface
| Standard SATA II HDD interface, SD / SDHC Card
|
Storage Capacity
| 2.5'' SATA II 2TB HDD,two 256GB SD/SDHC Card(suggest to use the SD Card with the
|
speed over Class10)
|
Storage mode
| stop when full or cycle recording
|
Camera
| CCD/CMOS
|
Video Technology
| H.264 (Data encryption, need to use the playback software to play the videos)
|
Video Standard
| PAL system or NTSC system
|
Video input
| Input standard: input frequency: Vp-p=1.0V,input impedance: 75Ù
|
Resolution
| 4ch 720P full real time recording, also support the playback function while recording.
|
Total frame rate
| PAL(1~100FPS optional)and NTSC(1~120FPS optional)
|
Video quality
| Main stream/Extra Stream mufti-grade adjustable
|
Output signal
| CVBS(4ch video + 4ch audio,but only support 1ch audio output at a same time)
|
Ethernet Port
| One 10M/100M Ethernet port (RJ45)
|
Alarm input
| 6ch independent alarm input port (with isolating function)
|
Alarm output
| 3ch independent alarm output port(4 ch DVR has two red indicator light display alarm
|
output state.)
|
USB Standard
| 1 USB 2.0 port(support USB back up and system upgrade)
|
Delay power off
| Delay duration :1minutes (default), we can OEM the delay duration.
|
3G/4G
| Support 4CH D1 real time video and audio transmission, including GPS info.
|
Other technology
| RS485(for PIZ connection),2.4G WIFI ,GPS(NMEA-0183) Timing and position
|
DVR dimension
| 146(Length)*138(Width)*40(Height)mm
|
mainframe weight
| Around 500g
|
