| Dimension | 48mm*46mm*40mm | |||
| Contact Feature | Form | 1Z(SPDT);1H(SPST-NO);1D(SPST-NC) | 2Z(DPDT);2H(DPST-NO);2D(DPST-NC) | |
| Rated load | 30A | |||
| Max switching voltage | 240VAC/28VDC | |||
| Contact resistance | ≤100mΩ | |||
| Material | AG Alloy(Agsno2; Agcdo) | |||
| Electrical life | ≥1*105 | |||
| Mechanical life | ≥1*107 | |||
| Operate voltage (23ºC) | DC:≤75%*Rated voltage, AC:≤80%*Rated voltage | |||
| Release voltage (23ºC) | DC:≥10%*Rated voltage, AC:≥30%*Rated voltage | |||
| Maximum voltage (23ºC) | 110%*Rated voltage | |||
| Coil voltage | DC6-220V, AC6-380V (Customize allowed) | |||
| Coil power | DC: 2.0W, AC: 4VA | |||
| Pick-up time | ≤25ms | |||
| Release time | ≤15ms | |||
| Dielectric strength | Between Same-pole contacts | 1500VAC/1min(leakage current 1mA) | ||
| Between Opposite-pole contacts | 1500VAC/1min(leakage current 1mA) | |||
| Between contacts and coil | 2500VAC/1min(leakage current 1mA) | |||
| Insulation resistance | ≥100mΩ(500VDC) | |||
| Ambient temperature | -25ºC ~55ºC | |||
| Ambient humidity | 45%-75%RH | |||
| Atmospheric pressure | 86-106KPa | |||
| Shock resistance | 10G (sinusoidal half-wave pulse: 11ms) | |||
| Vibration resistance | 10-55Hz (double amplitude: 1.5mm) | |||
| Installation | Screw | |||
| Weight | Approx. 70g/PCS | |||
| Packing | Carton with foam box inside | 120PCS/Carton, G.W.: 12KG, N.W.: 11KG, Dimension(mm): 400×265×345 | ||
