High Quality Full Automatic Double Nozzles Weighing Fiber Filling Machine

Product Description

Double Heads Six Scales Automatic Cotton Filling Machine( down can be also filled)
Product Parameters

Model	M2-6
Single Error	Within 0.5g
Filling nozzle size	32mm, 45mm
Daily workload	8000-16000 times
Filling type	Whole piece filling
Single weighing range	3-200g
Filling material	Silk cotton, ball cotton, down, wool silk
Dimension	2300*1200*1900mm
Installation Size	4000*2500mm
Cycle number of single head	3
Display Accuracy	0.1g
Machine weight	650kg
Power	380V/4KW
Filling port	2 pcs

Certifications
Company Profile Tangshan Hexin Garment Machinery Co., Ltd. is a modern production enterprise specializing in the manufacturing of garment machinery integrating research, development, manufacture and sales together. After years of R&D and experience accumulation, the company's products are sold to domestic market and overseas markets, such as South Korea, Vietnam, Myanmar, Cambodia, etc. The domestic market mainly includes Beijing, the three northeastern provinces, Anhui, Shandong, Wuhan, Tianjin, Hubei, Xinjiang, Henan, Chongqing and other major clothing production bases. The electric parts adopt well-known domestic and international brands, such as Delta PLC, German HBM sensor, Taiwan MEANWELL regulated power supply, Airtac pneumatic parts, Japanese SMC pressure regulating valve, CHINT Electric, etc. The company has advanced technology and strong scientific research strength, and is committed to creating higher value for customers and leading the garment machinery industry.
The company's main products include automatic down filling machine, automatic cotton filling machine, flow machine, automatic down filling machines, etc. single head with two weighings, single head with three weighings, single head with four weighings, single head with six weighings, double head with four weighings, double-head with six weighings, double-head eight weighings, double-head twelve-weighing, four-head sixteen-weighing automatic down filling machine and cotton filling machine, etc. In order to meet the personalized needs of customers, we can provide customers with tailor-made solutions.

Electrical parts

Name	Brand and Origin
PLC	Delta/Xinje
Sensor	HBM(Germany)
Regulated power supply	MW(Taiwan)
Controller	Delixi
Pneumatic parts	AirTAC
Pressure Regulating Valve	Japan SMC/AirTAC
Touch Screen	MCGS

---
