| US$32,000.00 | 1 SET (MOQ) |
| SPECIFICATION | LTY2000 PET | |||||||
| B | ||||||||
| INJECTION UNIT | ||||||||
| SCREW DIAMETER | mm | 70 | ||||||
| SCREW L/D RATIO | L/D | 25 | ||||||
| SHOT VOLUME(THEORETICAL) | cm3 | 1134 | ||||||
| INJECTION WEIGHT(PS) | g | 1224 | ||||||
| INJECTION RATE | g/s | 400 | ||||||
| INJECTION PRESSURE | MPa | 130 | ||||||
| SCREW SPEED | rpm | 126 | ||||||
| CLAMPING UNIT | ||||||||
| CLAMP FORCE | KN | 2000 | ||||||
| OPEN STROKE | mm | 475 | ||||||
| SPACE BETWEEN TIE BARS(W*H) | mm | 530x530 | ||||||
| MAX.MOULD HEIGHT | mm | 560 | ||||||
| MIN.MOULD HEIGHT | mm | 200 | ||||||
| EJECTOR STROKE | mm | 140 | ||||||
| EJECTOR FORCE | KN | 90 | ||||||
| OTHER | ||||||||
| MAX.PUMP PRESSURE | MPa | 16 | ||||||
| PUMP MOTOR POWER | kW | 18.537 | ||||||
| HEATING POWER | kW | 22.7 | ||||||
| MACHINE DIMENSION(L*W*H) | m | 6.5*1.8**2.3 | ||||||
| OILTANK CUBAGE | L | 300 | ||||||
| MACHINE WEIGHT | t | 7.2 | ||||||
