2 Layer Composite Materials Filter Paper Fiberglass Air Filter Paper

Product Description

2 Layer Composite Materials Filter Paper Fiberglass Air Filter Paper Product Description
Fiberglass Composite Filter Paper
This is a filter paper made of micro fiberglass mat single - or double-sided composite with polyester non-woven fabric protective layer. The structure can avoid secondary pollution caused by the falling off of the filter layer. Used to filter air and liquid, the product has high filtration efficiency, low resistance, high strength and large dust capacity. Filter impurities in the particle size of 1 ~ 70um, 1m wide of the finished product, delivery by roll.
Liquid filtration accuracy:1um, 2um, 3um, 5um, 10um, 20um, 25um, 30um, 40um, 50um, 70um;tensile strength:(KG/15MIN/):≥2.5
Air filtration accuracy:1um,5um,10um,25um;tensile strength:(KN/M):≥2.5;The filtration efficiency:65%, 90%, 99%, 99.9995%
Fiberglass air filter paper is made of glass fibers as main raw material by wet process. Characterized by stable property, uniform fiber distribution, high dust holding capacity, high efficiency, low air resistance and high strength, it is an ideal material for air filtration. Depending on the filtering efficiency, the products are divided into three series (ASHRAE, HEPA and ULPA).
Product Parameters

Class	Grade	Efficiency	Resistance	Tensile Strength	Thickness	Basic Weight	Stiffness
HEPA 0.3mm @5.3cm/s	H14	≥99.995%	≤420Pa	1.0-1.25KN/m	0.33±0.02mm	74±4g/m2	mg≥1000
	H13	≥99.97%	≤330Pa	0.9-1.20KN/m	0.33±0.02mm	74±4g/m2	mg≥1000
	H12	≥99.8%	≤260Pa	0.9-1.20KN/m	0.33±0.02mm	74±4g/m2	mg≥1000
	H11	≥98%	≤180Pa	0.9-1.20KN/m	0.33±0.02mm	74±4g/m2	mg≥1000
	H10	≥94%	≤120Pa	0.9-1.20KN/m	0.33±0.02mm	74±4g/m2	mg≥1000
ASHRAE 0.4mm @5.3cm/s	F9	≥95%	≤80Pa	0.9-1.15KN/m	0.33±0.02mm	70±4g/m2	mg≥900
	F8	≥90%	≤60Pa	0.9-1.15KN/m	0.33±0.02mm	70±4g/m2	mg≥900
	F7	≥80%	≤40Pa	0.9-1.15KN/m	0.33±0.02mm	70±4g/m2	mg≥900
	F6	≥60%	≤25Pa	0.9-1.15KN/m	0.33±0.02mm	70±4g/m2	mg≥900

Detailed Photos
Application
Our Advantages
Company Profile
FAQ
Q 1, Are you factory or trading company .
A ,We are a specialized manufacturer of filter paper in China ,we have our own brand .
Q 2, Can I make a OEM order ?
A,We can supply different sizes ,our products can be customized .
Q 3. ,Please let us know your payment term ?
A , TT ,LC ,DA, and DP etc ,
Q 4. What about your packages ?.
A , Carton box with pallet .
Q 5 .May I have one sample before the order ?
A, The samples are free of charge for delivery .
Q 6 , Could you please show us the delivery time ?
A , Within 2 weeks after confirming the PI .

---
