Horizontal Shenzhou Phone Case Machine LED Cover Injections Machines with CE

Product Description

Product Description
Product Paramenters

SZ-1300A INJECTION UNIT
ITEM	UNIT	VALUE
SCREW DIAMETER	mm	35	40	45
SCREW L/D RATIO	L/D	24	21	18.7
Theoretical Shot Volume	cm^3	173	226	286
SHOW WEIGHT(PS)	g	158	206	260
INJECTION PRESSURE	Mpa	235	180	142
THEORETICAL INJECTION RATE(PS)	g/s	110	143	181
PLASTICISING CAPACITY	g/s	13.8	19.7	27.1
SCREW TORQUE	N.m	740
MAX.SCREW ROTATE SPEED	r/min	250
INJECTION STROKE	mm	180

SZ-1300A CLAMPING UNIT
ITEM	UNIT	VALUE
MAX.CLAMPING FORCE	KN	1300
MAX.OPENING STROKE	mm	400
SPACE BETWEEN TIE BARS	mm	420*420
MOULD HEIGHT	mm	160-440
MAX.DAYLIGHT	mm	840
EJECTOR FORCE	KN	31.4
EJECTOR STROKE	mm	100
EJECTOR QUANTITY		5

SZ-1300A OTHER
ITEM	UNIT	VALUE
PUMP MOTOR POWER	kw	13
PUMP PRESSURE	Mpa	16
HEATING POWER	kw	9.2
HEATING ZONE		4
SIZE	m	4.7*1.25*1.85
NET WEIGHT	t	4.3
OIL TANK CAPACITY	L	360
INTERNATIONAL DESIGNATION		1300-410

New type 5-point toggle device of stable movement curve,gentle shock. Superior mould platen to ensure no out of shape if high-pressure clamping.
Hard chrome plated high tensile strength tie bars made of superior alloy.
Wear-resistant guide for moving platen.
Transducer control clamping stroke.
Many step control for speed and pressure of clamping and opening.
Eiection device offer dwell,single,more, vibration function.
Low pressure mould protection function.
Hydraulic mould height adjustment with roungh and fine operation.
Mechanical and electrical dual safety interlock.
Automatic centralized lubrication system with far pressure detector.
Proportional pressure and flow control with fine adjustment and precision. Know-how manifold design,compact,reasonable and fast respond.
Imported world famous hydraulic valves.
Imported world famous hydraulic sealing rings.
Imported technology hydraulic hose and fittings.
Low noise hydraulic system.
Precision oil filter and oil cooler.
Nitrided screw and barrel with long service life. Smelted screw with big L/D ratio with good plasticizing and color-fixing.
Double injection cylinder of compact construction and good equilibrant.
Transducer control injection stroke.
The speed of low speed and large torque hydraulic motor can be adjusted.
Screw back pressure control and nozzle anti-leakage control movable hopper for easy remove material.
Injection-catriage can be used for slacking,re-feedingor fixed-feeding.
Speed and pressure of injecting and holding controlled by time or position.
Equipped with reverse device to be easily removed and cleaned.
