Pipe Making Machine SSAW Automatic Spiral Welded Tube Machine; Oil Mill

Product Description

Introduction:
Spiral Welded Pipe Making Equipment is mainly used to produce spiral steel pipes. The steel coils are unfolded and leveled by the spiral welded pipe mill. Then they are sent to the forming machine in a certain angle. Supplemented by a certain angle, the continual pipes are formed in the three-roll rolling machine. Continual spiral welding is performed by submerged-arc welding machine. The products spiral welded pipes can be used in fluids transmission service and ordinary structure supports.
Reference Project
TheΦ2200 × 22mm spiral welded pipe mill is to uncoil the steel coil into steel strip which is formed by forming machine to make spiral welded pipe. Φ406-Φ2200 spiral welded pipe mill apply front swing type mill. The spiral welded pipes are mainly used as delivery pipeline for petroleum, natural gas, water, coal gas, as well as structural pipe and piling pipe.
Machine parts in the working line
1) Uncoiled
2) Pinching & leveling machine
3) Manual/Electrical roll
4) End - Cutting & butt-welding machine
5) Rotary shear
6) Delivery machine
7) Guide board
8) Forming unit
9) Front bridge
10) Inside/outside welding device
11) Rear bridge
12) Flying saw cutter
13) Buried parts
14) Hydraulic system
15) Electric system
16) Inside/outside welder
17) Butt-weld car
18) Plasma cutter
19) Weld flux processing device
20) Beveling & end-facing machine
21) Hydraulic tester
22) Finishing equipment
Model
HUAYE with Customer
Loading and Shipping

---
