UV/460 PVC Injection Molding Machine

US$1.00-2.00 1 Piece (MOQ)

Basic Info.

Model NO.
UV/460
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Certificate of Origin
1
Certificate of Fumigation
1
Packing List
1
Commercial Invoice
1
Easy Broken Parts
1
Trademark
K&E
Origin
China
HS Code
8477101090
Production Capacity
200/Y

Product Description

PVC IMM :
Cooling fan installed on barrel,Widened protective door.,Increased motor.
The main production of PVC material pipe fittings
Parameters:
PVC STYLE SPECIFICATION UV/460
SCREW TYPE A B C D
Injection Unit
Screw diameter mm 75 80 85 90
Screw L/D ratio L/D 22 20.6 19.4 18.3
Shot volume(theoretical) CM3 1767 2010 2269 2544
Injection weight(PVC) g 2251 2561 2891 3241
Injection rate g/s 498 567 640 717
Injection pressure MPA 191 168 149 133
Screw speed rpm 100
Clamping Unit
Clamping force KN 4600
Open stroke mm 780(790)
Space between tie-bars(W*H) mm 780*780
Max mould height mm 800
Min mould height mm 250
Ejector stroke mm 220
Ejector force KN 110
Others
Max pump pressure MPA 16
Pump Motor power KW 52
Heating power KW 29.3
Numbers of heating area Segment 5+1
Machine dimension(L*W*H) M 8.05*2.10*2.8
Oil tank cubage L 695
Machine weight TON 18

Configuration List:
Name Brand
Computer KEBA(AUSTRIA) or EST
Servo Drive INOVANCE(CHINA)
Servo Pump SUNNY(USA) / SUMITOMO(JAPAN)
Servo Motor PHASE(ITALY)
Electro-hydraulic Proportion valve HNC (Taiwan)
Stroke transducer NOVO or Miran(GERMANY)/GERFRAN(ITALY)
Breaker Schneider (FRANCEN)/Siemens(GERMANY)
Contacts Schneider (FRANCEN)/Siemens(GERMANY)
Switch Schneider (FRANCEN)/Siemens(GERMANY)
Hydraulic Direction Valve Vickers (USA) or Rexroth (GERMANY)
Plasticing Motor DINAMIC(ITALY) or STF(ENGLAND)
Hydraulic Hose MANULI(ITALY)/CONTINENTAI(GERMANY)
Plasticing speed sensor OMRON
Sealing ring HALITE or TREIIEBORG(UK or GERMANY)
