UL1180 PTFE Wire Electrical Wires Heating Cable

Product Description

Product Description UL1180 customized highly quality PTFE wire electrical wires heating cable

UL Style 1180 Hook-up Wire
Conductor: Nickel or Silver Copper				Insulation: PTFE
Operating Temperature:200ºC				Rated Voltage:300V DC
Flame resistance: VW-1 or FT1				RoHs Compliant
Standard:UL758, UL1581
Gauge	No.of Strands	Diameter of Strands MM	Diameter of Conductor	Resistance at 20ºC Ω/KM	Insulatio Thickness MM	Overall Diameter MM
						Normal	Tolerance
10	19	0.574	3.06	3.54	0.35	3.80	±0.15
12	19	0.455	2.36	5.64	0.35	3.10	±0.15
14	19	0.361	1.85	8.96	0.35	2.60	±0.10
16	19	0.287	1.50	14.60	0.33	2.16	±0.10
18	19	0.235	1.18	23.20	0.33	1.84	±0.10
20	19	0.19	0.95	36.70	0.33	1.60	±0.10
22	19	0.15	0.76	59.40	0.33	1.40	±0.10
24	7	0.20	0.61	94.20	0.33	1.26	±0.10
26	7	0.16	0.48	150.00	0.33	1.15	±0.10
28	7	0.10	0.38	239.00	0.33	1.05	±0.10
1 Copper tolerrance:±8‰
2 Color Code: BK-Black WT-White YL-Yellow BR-Brown GN-Green RD-Red OG-Orange GY-Grey BL-Blue VT-Violet GNYL-Gn/YL
3 Custmized Spec is vailable based on customer request

Packaging & Shipping
Company Profile Phine Group, As one of the most leading wire and cable , lighting and connector products manufacture in Guangdong China, Located in Pearl River Delta with developed economy and convenient transportation, is on HIGH-TECH enterprise focus on producing, sale and service of indoor lighting, wire and cable. Our company is headquartered in Shenzhen, with branch factories located in Zhongshan, Dongguang, Huizhou and other places. All the products have been exported to Europe, American and southeast Asian countries.
PHINE Group was founded in 2010, which locates in zhongshan city-China Lighting Capital. Is a leading manufactory and supplier of all kinds of UL wire/cable, indoor lighting and connector . We sales very well all over the world.
Our special style and qualified products created by all the staff with their dedication and the spirit of striving for the perfection had been highly trusted and praised by the customers around the world. From now on, we will insist on the best quality and innovation, pursue the excellence and the sustainable development by keeping the principle of the customers satisfaction is our great achievements as before.
Facing the new globalized competitive environment, Phine Group will accomplish great strength, relying on innovation-driven development, with quality cast the future, and strive to create a world influence of international industry group.
Welcome customers to negotiate with us, thank you!
Our profession, our quality & our service will be your best choice!
Our Goal: Connect all over the world!
FAQ 1.Do you accept partial shipment? Yes, partial shipment is accepted. But the freight shall be covered by yourself.2.When the goods have quality problem, will you send us the replacement? If the cable has quality problem, please send us the details, like the quantity of defective cable, pictures and labels.When we confirm it, the replacement will be shipped together with your next order.3.Can I order the cable which is lower than your MOQ? First, we will check the inventory. If it is in stock, sure, it is ok. But if it was out of stock. When your quantity is closed toour MOQ, it is ok.If it is much less than our MOQ, we will take it as a sample order, so the price will be a little bit higher.

---
