Lonking 50 Ton Excavator Cdm6490 LG6490

US$45,000.00-85,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
CDM6490
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Grab Shovel
Transmission
Hydraulic Transmission
Drive Type
Electric Drive
Bucket Capacity
>1.5m³
Size
Large-Scale
Certification
CE, ISO9001: 2000
Condition
New
Self Weight
48200kg
Ground Pressure
78.6kpa
Travel Speed
3.3/5.3 Km/H
Rotating Speed
9.1rpm
Gradeability
35%
Engine Model
Qsmii
Power
269/1850 Kw/Rpm
Fuel Tank Capacity
690L
Displacement
11.04L
Boom Length
7060mm
Arm Lenghth
3380mm
Bucket Radius
1800mm
Working Pressure
34.3MPa
The Max Bucket Digging Force Kn
262kn
The Max Arm Digging Force
233kn
Transport Package
by Roro, Bulk Cargo or Container Transprot
Specification
50 Ton
Trademark
NEWINDU
Origin
Shanghai, China
HS Code
84295100
Production Capacity
50 Uint/ Month

Product Description

LONKING 50 Ton Excavator CDM6490 LG6490
Feature
The environment-friendly and energy-saving engine
the originally imported engine features strong power, stable performance, fuel economy and high efficiency, low noise, lowvibration, and low emission, as well as low temperature start.The imported compound radiator of famous brand: reasonable structure, convenient to clean, and low temperature start.Both the inlet system and fuel system adopt 3-stage filter, which ensures the cleanness of air and fuel, and more suitable to tough work conditions.Reliable Hydraulic System
It adopts variable control system, which is the most advanced configuration at current market. It can change the system pressure and make reasonable flow distribution according to load condition, which contributes to the strong digging capacity all the time and the optimization of the system, and thus maximized the engine efficiency.Safe Cab and Comfortable Operation Environment
The ergonomics cab features clean profile, wide view, and delicate inside upholstering.The large capacity air conditioner with reasonable layout of wind outlet, which makes it more comfortable to work.
Parameters



Whole machine
 Overall quality
 48200
 kg
Bucket capacity
 2.2
 m3
Bucket capacity range
 2.0-2.2
 m3
Ground pressure
 78.6
 kPa
Walking speed (low, high)
 3.3/5.3
 km/h
Swing speed
 9.1
 rpm
Gradeability
 35
 °
Engine
 model
 QSMII
power
 269/1850
 kW/rpm
Displacement
 11.04
 L
Fuel tank capacity
 690
 L

Hydraulic system
 Work pressure
 34.3
 MPa
flow
 340×2
 L / min
Fuel tank capacity
 310
 L

Working equipment
 Boom length
 7060
 mm
Stick length
 3380
 mm
Bucket radius
 1800
 mm

Digging power
 Maximum digging force of bucket
 262
 kN
Maximum digging force of stick
 233
 kN
