| US$69,500.00-88,800.00 | 1 Piece (MOQ) |
| cabin | Driving type 4x4 | ||
| New Howo cab, with threeseats,with A/C. Left Hand /Right hand Drive. 70°hydraulically tillable to the front as attached photo for ref. | |||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8500x2450x3600 | |
| Wheel base (mm) | 4500 | ||
| Wheel track (front/rear) (mm) | 2005/2092 | ||
| Approach/Departure angle(°) | 32/22 | ||
| Weight in KGS | Tare Weight | 11800 | |
| Loading Capacity | 8000 | ||
| Front axles loading capacity | 1x9000 | ||
| Rear axles loading capacity | 1x16000 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | Sino Truck engine | |
| Model | MC11.40 | ||
| Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 400HP | ||
| Emission standard | Euro 5 | ||
| Gearbox | HW19710C, 10 forwards & 2 reverse | ||
| Clutch | Diaphragm spring clutch | ||
| Steering Gear | Power steering | ||
| Fuel tank (L) | 400 L | ||
| Tire | 315/80R22.5 All radial tubeless tires with one spare, 7 pieces | ||
| Compression garbage box body system | |||
| BodyVolume | 12 CBM | ||
| Cycle Time of Filling(S) | ≤40 | ||
| Lifting Time of Filler(S) | 8-10 | ||
| Time of Discharging | ≤60 | ||
| Working Pressure(MPA) | 16 | ||
| Composed by hermetic garbage tank, hydraulic system, operation system. The entire truck is hermetic, can automatically compress and dump the garbage .and the sewage generated in the process of the compression all go into the sewage tank. | |||
| Dispensing System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. 2. Automatic loading, compressing and discharging, all handled by 1 person. 3. Sewage water collection tank to avoid any pollution during handling. 4. Large Pressure, Good Leakage Proof, Convenient Operation Dependable Security. 5. Electrical Control Panel for compacting system. | |
