2024 Fast Delivery Construction Equipment 33ton Crawler Excavator

Product Description

Product Description

ZG330 Crawler Hydraulic Excavator
Introducing the ZG330 crawler hydraulic excavator, equipped with a TOP brand engine compliant with the 3-stage emission regulations, delivering powerful, energy-efficient, and reliable performance. Its advanced negative flow hydraulic system ensures comfortable operation, high efficiency, and excellent cost performance. With full power control and four power modes, it adapts seamlessly to various work conditions. The precise fuel injection system controls fuel quantity in real-time, enhancing combustion completeness and fuel efficiency. Structural integrity is ensured through full 3D modeling and finite element analysis technology.
Key Features:
1. High-Power Engine: The engine new generation high-power EFI engine offers strong power, low fuel consumption, and high reliability, providing optimal performance for demanding tasks.
2. Advanced Hydraulic System: The new hydraulic system features a large displacement main pump and main valve, ensuring smooth operation, minimal pressure loss, and better coordination for effortless operation.
3. Enhanced Digging Force: Equipped with large-bore oil cylinders and optimized hinge point arrangements, the excavator boasts improved digging force. It also features an automatic supercharging function that increases digging force with load, along with a large displacement slewing motor and gear design for enhanced rotation.
4. Mining-Optimized Configuration: Standard configurations include a heavy-duty reinforced boom, mine-specific short stick, and large-capacity rock bucket, along with an extended and widened heavy-duty chassis for improved stability in harsh mining conditions.
5. Intelligent Monitoring System: Equipped with a high-resolution, high-brightness 5.7-inch color anti-glare monitoring instrument and an intelligent electronic monitoring system, providing various functions such as vehicle maintenance information prompts, fault self-diagnosis, and alarms.
The ZG330 crawler hydraulic excavator sets a benchmark in performance, efficiency, and reliability, making it the ideal choice for various excavation tasks across different industries.

•Equipped with Top brand engine, high load resistance, high horsepower output, high reliability, low fuel consumption, significantly reduce the use and maintenance costs •Advanced negative flow hydraulic system is adopted, which has better system stability and reliability, faster compound action speed and higher operating efficiency. •High-strength reinforced box-type side beams and X-shaped middle frames, high-reliability towline wheels and track rollers, can withstand the impact caused by excessive loads.

ITEM		UNIT	Technical specifications
			ZG330
Operating weight		Kg	31880
Rated power		KW/rpm	241/2000
Rated bucket capacity		m3	1.6
Overall length	A	mm	10700
(600mm) Overall width(600mm track)	B	mm	3280
Overall height	C	mm	3546
Platform width	D	mm	3060
Height of cabin	E	mm	3145
Ground clearance of counterweight	F	mm	1193
Engine cover height	G	mm	2563
Min. ground clearance	H	mm	471
Tail length	I	mm	3205
Turning radius of turntable	I'	mm	3250
Wheel base of track shoe	J	mm	4030
Length of chassis	K	mm	4950
Width of chassis	L	mm	3280
Track shoe gauge	M	mm	2680
Standard track width	N	mm	600
Max. traction		m3	273
(/) Traveling speed (H/L)		Km/hr	5.1/3.1
Swing speed		rpm	10.0
Gradeability		Degree(%)	35(70%)
Ground pressure		Kgf/cm2	0.594
