Multi-Layer Metal Dryer Paper Egg Tray Machine/Apple Tray Machine/ Egg Carton Making Machine for Chicken Farms

Product Description

Multi-layer Metal Dryer Paper Egg Tray Machine/Apple Tray Machine/ Egg Carton Making Machine for Chicken Farms
This type semi-automic egg tray machine production line is not equipped with drying system, after mixing pulp process and automatic forming process, the wet egg trays will be moved to another place for drying by workers, and then prodcut can be dried by sunshine.
the semi-automatic egg tray production line is suitable for all kinds of paper pulp molded product.
It includes forllowing parts:
1. Pulping System:

Put the waster paper into the hydrapulper , the paper and water will mix in hydrapulper ,then go to the refiner machine ,refiner machine make the pulp more small and uniform ,then the pulp pump absorb the pulp to the pulp pool .after the second mix in the pulp pool ,the pulp will go to the form machine pulp tank .

2. Forming System :

The vacuum pump will offer the vacuum to make the forming mould absorb the pulp from the pulp tank. One PLC cabinet will control the pulp absorb time ,the finished product will be shaped on the forming mould ,then the transfer mould transfer the products to the drying line ,the air compressor will give the air to blow the products ,then the products will drop down from the mould .Then the products is delivered to the drying line automatically; the water will go back to the water pool recycled.
Technical Specification of the Egg tray machine

.	Egg tray mould quantity		1pcs	2pcs	3pcs
2.	Raw material		Waste paper	Waste paper	Waste paper
3.	Output for egg tray		350pcs/hour	700pcs/hour	1000pcs/hour
4.	Net weight per piece (gram)		70g-75g	70g-75g	70g-75g
5.	waste paper consumption		0.025ton / hour	0.053ton / hour	0.1ton / hour
6.	water consumption		0.075ton / hour	0.15ton/hour	0.15ton / hour
7.	Operators number		2-3workers	3-4workers	4-6workers
8.	Area of workshop	Without dryer	≥100M²	≥100 M²	≥ 120 M²
9.	Capacity of power	Without dryer	20KW	30KW	40KW
10.	Machine length	Without dryer	7meters	8meters	9meters
11.	Size of container	Without dryer	20ft*1	20ft*1	40ft*1

FAQ:
Our productionline has Fully Automatic and Semi Automatic two types , both have computer control system .
1. What is Semi Automatic type ?
If only order The 1st and 2nd compulsory parts , that's Semi Automatic because you'll have to do the work of drying up egg tray manually;
2. What is Fully Automat type ?
Meaning: the production line includes the Drying system and the whole procedure can be done Automatically .
Of course, the price and the required work space would have big difference from the semi-automatic type.
3. Quality
--- Our machines use UK Technics and part of the components are Germany-made (ex: Ball valve) .
-- Our machine is made by Tooling NOT by Welding , insuring a minimum of 10 years' lifespan .
-- The Egg tray moulds material is Aluminium which can keep the fixed shape much better than that made of rubber material.
--- 99.9% of Success rate: Even if there is a failed egg tray , just throw it back to Pulping area and it can be re-used avoiding waste ;
--- Our machine has been sold to worldwide for over 10 years with continued re-order by some customers with their business grow .

---
