Hydraulic Crawler Excavator Xe265c 1.05-1.25m3 Bucket 25.5 Ton Large Crawler Excavator

Product Description

Hydraulic Crawler Excavator XE265C 1.05-1.25M3 Bucket 25.5 ton Large Crawler Excavator Engine:
The imported engine with original packing has more forceful power and low fuel consumption. The optimized match of system guaranties that the overall performance gives full play to the full unit.
Hydraulic system:
The imported hydraulic parts with high-level configuration are of rational and high quality match and excellent performance.
Up-to-date fuel filter:
By use of an up-to-date fuel filter,the filtration performance has been improved,the oil-taking quality guaranteed and the operation reliability of engine under severe operation conditions enhanced.
Protection against shocks
By use of an liquid sealed shockproof rubber,the oscillation and noise in cab have been further reduced and the fatigue of operating personnel relieved. The application of high-strength enclosed structure increases the strength and rigidity of whole cab.
Large cab space
The indoor space of new luxury cab has been enlarged for 360°view, which can build up a pleasant working environment for the operator.

Specification:

Description				Unit	Parameter value
Operating weight				kg	25500
Bucket capacity				m³	1.05~1.25
Engine		Model		Engine
		Style	Direct injection	---	√
			Four strokes	---	√
			Water cooling	---	√
			Turbo-charging	---	√
			Air to air intercooler	---	√
		No. of cylinders		---	6
		Output power		kW/ r/min	135.5/2150
		torque/speed		N.m	637/1800
		Displacement		L	6.494
Main performance		Travel speed(H/L)		km/h	5.9/4.0
		Rotating speed		r/min	11.3
		Gradeability		°	≤35
		Ground pressure		kPa	50.1
		Bucket digging force		kN	179
		Arm digging force		kN	125
		Maximum traction		kN	194
Hydraulic system		Main pump		--	2
		Rated flow of main pump		L/min	2×256
		Pressure of prime valve		MPa	34.3/37
		Pressure of travel system		MPa	34.3
		Pressure of swing system		MPa	28
		Pressure of pilot system		MPa	3.9
Oil Capacity		Fuel tank capacity		L	400
		Hydraulic tank capacity		L	240
		Engine oil capacity		L	25
Appearance size		Overall length		mm	10160
		Overall width		mm	3190
		Overall height		mm	3100
		Width of platform		mm	2830
		Length of crawler		mm	4640
		Overall width of chassis		mm	3190
		Width of crawler		mm	600
		Wheel base of crawler		mm	3842
		Crawler gauge		mm	2590
		Clearance under counterweight		mm	1100
		Min. ground clearance		mm	485
		Min. tail swing radius		mm	2985
Working scope		Max. digging height		mm	9662
		Max. dumping height		mm	6810
		Max. digging depth		mm	6895
		Max. digging depth at the range of level 8 feet		mm	6750
		Max. vertical wall digging depth		mm	5480
		Max. digging reach		mm	10240
		Min. swing radius		mm	3850
Worker	Standard	Length of boom		mm	6000
		Length of arm		mm	2960
		Bucket capacity		m³	1.2
	Optional	Length of boom		m³
		Length of arm		m³	2500
		Bucket capacity		m³	1.25/1.05

---
