| PET STYLE SPECIFICATION | UE/360 | ||||
| SCREW TYPE | A | B | C | D | |
| Injection Unit | |||||
| Screw diameter | mm | 60 | 67 | 70 | 75 |
| Screw L/D ratio | L/D | 25 | 25 | 25 | 25 |
| Shot volume(theoretical) | CM3 | 947 | 1181 | 1289 | 1480 |
| Injection weight(PET) | g | 1181 | 1472 | 1607 | 1845 |
| Injection rate | g/s | 381 | 474 | 518 | 595 |
| Injection pressure | MPA | 231 | 186 | 170 | 148 |
| Screw speed | rpm | 160 | |||
| Clamping Unit | |||||
| Clamping force | KN | 3600 | |||
| Open stroke | mm | 675(705) | |||
| Space between tie-bars(W*H) | mm | 680*680 | |||
| Max mould height | mm | 720 | |||
| Min mould height | mm | 250 | |||
| Ejector stroke | mm | 180 | |||
| Ejector force | KN | 70 | |||
| Others | |||||
| Max pump pressure | MPA | 16 | |||
| Pump Motor power | KW | 45.2 | |||
| Heating power | KW | 24.7 | |||
| Numbers of heating area | Segment | 4+1 | |||
| Machine dimension(L*W*H) | M | 7.38*1.95*2.55 | |||
| Oil tank cubage | L | 510 | |||
| Machine weight | TON | 13.5 | |||
| Name | Brand |
| Computer | KEBA(AUSTRIA) or EST |
| Servo Drive | INOVANCE(CHINA) |
| Servo Pump | SUNNY(USA) / SUMITOMO(JAPAN) |
| Servo Motor | PHASE(ITALY) |
| Electro-hydraulic Proportion valve | HNC (Taiwan) |
| Stroke transducer | NOVO or Miran(GERMANY)/GERFRAN(ITALY) |
| Breaker | Schneider (FRANCEN)/Siemens(GERMANY) |
| Contacts | Schneider (FRANCEN)/Siemens(GERMANY) |
| Switch | Schneider (FRANCEN)/Siemens(GERMANY) |
| Hydraulic Direction Valve | Vickers (USA) or Rexroth (GERMANY) |
| Plasticing Motor | DINAMIC(ITALY) or STF(ENGLAND) |
| Hydraulic Hose | MANULI(ITALY)/CONTINENTAI(GERMANY) |
| Plasticing speed sensor | OMRON |
| Sealing ring | HALITE or TREIIEBORG(UK or GERMANY) |
