| US$50,000.00-80,000.00 | 1 SET (MOQ) |
| Descriptions | Unit | Data | |
| Nominal Force | Cutting | By Sawing 305mm | |
| Flaring | KN | 300 | |
| X Axis Speed | m/min | 48 | |
| Chief Clamp Stroke X1-Way | mm | 1500 | |
| Aided Clamp Stroke X2-Way | mm | 2000 | |
| Y Axis Stroke | mm | 250 | |
| Flaring Stroke | mm | 30 | |
| Station | Sawing | Set | 1 |
| Flaring | Set | 1 | |
| Tolerance | mm/m | ±0.2 | |
| Air Source | MPA | 0.6-0.8 | |
| Max Sheet Size(L×W×T) | mm | 6000×120×7mm | |
| Min Sheet Size(L×W×T) | mm | 500×50×5mm | |
| Total Power | kW | 12KW | |
| Machine Size:L×W | mm | 15000*3000mm | |
| Control Unit | ||
| No. | Descriptions | Brand |
| 1 | PLC | OMRON |
| 2 | Sensor | Telemacanique fm Schneider |
| 3 | Control Button | OMRON |
| 4 | Touch Screen | OMRON |
| 6 | AC Contactor | ABB |
| 7 | MCCB | ABB |
| 8 | Switch | OMRON |
| 9 | Hydraulic Motor | WN |
| 10 | Servo Motor | YASKAWA |
| 11 | Servo Driver | YASKAWA |
| Transmission Unit: | ||
| Serial number | Name | Brand |
| 1 | Precise Guide Rail | Taiwan HIWIN |
| 2 | Precision ball screw | Taiwan HIWIN |
| 3 | Bearing | Japan NSK |
| Hydraulic Unit: | ||
| Serial number | Name | Brand |
| 1 | Solenoid Valve | ATOS |
| 2 | High-pressure Pipe | Riva flex |
| 3 | High pressure oil pump | SG Piston of Rexroth |
| 3D Smartbar Design Software | |
| Finished Joggling |
