China Top Mnufacturer for CNC Angle Punching Marking and Cutting Machine for Transmission Tower Fabrication, Steel Fabrication, Plate Processing

Product Description

Product Description
I. Product Feature
1.TBL1412, TBL1412A two sets of punches on each side, TAPM1412 three sets, can process all holes once time.
2.TBL1412A, TAPM1412 Single blade shearing, save raw material.
3. Numerical control processing, the operation is very convenient, can realize automation, high precision, many varieties, mass production.
4. Marking unit adopts closed frame with good rigidity. On the marking unit is equipped with four groups of programmable selection box.
5. With avoided shearing functions, so as to process fixed-length angles.
6. All marking, punching and shearing in automatic completeness, all finished angles can be unloaded by pneumatic turnover device so as to lighten the working strength.
7. Easy programming, adopt instruction programming and lofting software. It can read. NC1 files generated by TEKLA software.
Detailed Photos

Product Parameters

Model	TAPM1412
Angle size (mm)	40x40x3~140x140x12
Max. Punching (dia. x thi.) (mm)	Φ26x12
Punching force (kN)	1000
Marking force (kN)	1030
Cutting force (kN)	1800
Max. length of blank (m)	12
Max. length of finished (m)	12
Punches per side	3
Group of Marking letters	4
Dimension of letter (mm)	14x10x19
CNC axes	3
Shearing mode	Single blade shearing
Feeding speed of angle (m/min)	80
Programming mode	Lofting software or instruction program
Overall dimensions (mm)	≈26000x7000x3000
Gross Weight of machine (kg)	≈16500
Total power (kW)	43

---
