Hot Sale Stone Cutting Engraving Sculpture CNC Router Machine

Product Description

hot sale stone cutting engraving sculpture cnc router machine Heavy duty steel structure, keep machine with very good stability. Adopt good quality machine parts,to make machine with high performance and durability. Multi-function, machine is with both rotary device and flat able,can process 3d columns,also can process plane materials. The big rotary device can process different kinds of 3d roman columns corbel pilasters cylinders pillars. With saw blade function,for fast rough machining,10 times saved working time.

Model No.	JCS1530L
Lathe bed	heavy duty steel structure
Table	Removable,T-slot with clamps
Flat Working size	1500*3000*500mm
Rotary Working size	800mm diameter, 2000mm length
Spindle power	5.5kw /7.5kw BT30 water cooling ATC spindle
Spindle rotating	18000 /24000rpm
Max.travelling speed	55m/min
Max.working speed	20m/min
Tool magazine	Linear type automatic tool changer, 8 tools ability
Control system	4 Axis Nsctudio /Syntec
Motor	Servo
Saw blade unit	yes
Auto oil system	yes
Voltage	AC380v,3 phase,50Hz

It can work on many materials like Marble, Granite, Artificial Stone, Terrazzo, Limestone, Sandstone,Travertine, Quartzite,
Slate, Grindstone ,Jade, Crystal, Glass, Acrylic, Wood, PVC, EPS Foam, Aluminum composite panel, Aluminum block, Copper and so on.
1. Sample testing before shipment
2. Provide 2 days free training for each machine
3. 12 months warranty for each machine
4. Friendly English version manual and operation videos for studying
5. Free technical support by phone,email,chatting or remote
6. Engineers available to service machinery overseas

---
