Wood MDF PVC Plastic Engraving Cutting 3D CNC Router

Product Description

Wood MDF PVC Plastic Engraving Cutting 3D CNC Router
Production introduction:
This machine design is half cylindrical design used to do 3d working, and another table you can do the normal engraving, cutting for nonmetal materials, like acrylic, wood, foam, pcb, etc. With two spindle equipped on machine to get wider use of the machine.
The general features of the machine are as following:
1.The machine body is strong, rigid, high precision, reliable and durable.
2.Imported high-precision ball screw gap, smooth movement, to ensure that the machine tools high-precision
3.Using well-known domestic brands of water-cooled brushless spindle, low noise, strong cutting ability, to ensure the long time working.
4.Good three-axis and dust-proof structure to ensure that the machines longer service life.
5.Designer perfectly, select the best machine accessories , to minimize the failure rate preferred.
6.Breakpoint specific memory, power outages continued carving, processing time forecast, and other functions to ensure that accidental processing .
7.Compatility, compatible Type3/ Artcam/ Castmate/Wentai, and so on a variety of CAD/CAM designsoftware.

specifications:	Model	DW1325 cylinderical cnc router
1	X,Y,Z Working Area	1300x2500x200mm
2	Table Size	1380×3040mm
3	X,Y,Z Traveling Positioning Accuracy	±0.05/300mm
4	X,Y,Z Repositioning Positioning Accuracy	±0.05mm
5	Table Surface	Bakelite Vacuum Ttable (Option:T-slot table)
6	Frame	Welded strucutre
7	X, Y Structure	Rack and Pinion Drive,Hiwin Rail Linear Bearings
8	Z Structure	Ball Screw, Hiwin Rail Linear Bearings
9	Max.Power Consumption (Without spindle)	3.0Kw
10	Max.Rapid Travel Rate	50000mm/min
11	Max.Working Speed	25000mm/min
12	Spindle Power Motor	34.5kw water cooling or HSD for choice
13	Spindle Speed	0-24000RPM
14	Drive Motors	Stepper system(Option:Servo System)
15	Working Voltage	AC220V/50/60Hz,1PH (Option: 380V 3PH)
16	Command Language	G Code
17	Operating System	DSP System (Option: Mach3 PC Software)
18	Interface	USB
19	Flash Memory	128M(U Disk)
20	Collet	ER25
21	X,Y Resolution	<0.02mm
22	Software Compatability	Type3 software,Ucancam software(Option:Artcam software)
23	working temperature	0ºC~45ºC

Parts of the machine can do some changes as your requirement:
1. Motor (stepper or sever motor)
2. Spindle ( air-cooling or water-cooling spindle)
3. Guide rail (round guide rail or square guide rail)
4. The table of the machine (Vacuum table, T-slot table, Combination of Vacuum table & T-slot table, normal table, table moving)

3d models cnc engraver Standard accessories
DSP handle, cable, Water cooling system, Power cable, Clamp, Wrench, Bit, Collet, Other tools
Company Advantages
1, First-class factory meets international production plant's standard, ten years' manufacture and export experiences
2, Own most advanced domestic cnc machining production equipments
3, 5-9 days machine production time, one year warranty and lifetime free maintenance
4, OEM and ODM services available
5, Same quality, our price and service are better; Same price, our quality and service are better
6, with CE, FDA, SGS, ISO9000 certifications
DWIN Factory sets VR ( real place photo taken) please visit the following pages
http://dwinlaser.en.made-in-china.com
Machine details:
Machine Samples:
Customers:

---
