5 Axis Vmc CNC Milling Machine Equipment

Product Description

Welcome to Nantong AJ Industry Limited! Feel free to inquire about our top-notch 5 Axis VMC CNC Milling Machine Equipment at our leading factory.
5 Axis VMC CNC Milling Machine Equipment
Explore our Vertical CNC Machine Tool for precise Industrial Cutting. Automated CNC Machining Center for advanced milling solutions.
Nantong AJ Industry Limited presents the VMC640 with a 950x400mm worktable and travel of 700x450x500mm. This 5 Axis VMC CNC Milling Machine Equipment offers high precision and advanced CNC machining capabilities.
Product Description
Specifications:
Spindle: BT40 10000rpm or 12000rpm (Taiwan make)
Travel: 900x600x700mm
Roller guideways: width 35/45/45mm (brand: Hiwin/PMI)
Hiwin ballscrew: diameter 40mm, C3 class with lock nuts
ATC: brand OKADA of 24 tools side mounted
Chain type chip conveyor
Main Configuration & Accessories:
Resin sand casting, Meehanite HT-300
X, Y, Z rails adopt stainless steel telescopic cover
Roller type linear guideway from Taiwan
Ball lead screw from Taiwan
Standard with belt-driven spindle, optional for direct-driven spindle
Taiwan pneumatic cylinder
Taiwan ATC, umbrella type and disc type are available
Import bearings for leadscrews
Import coupling
Headstock Nitrogen balance system as an option
Full enclosed cover
Rigid tapping
Spindle center ring blast
Work lamp
Pilot lamp
USB and Internet interface
Manual pulse generator (MPG)
Centralized automatic lubrication system
Cooling system
Heat exchanger for electrical cabinet
Leveling blocks & bolts
Toolbox and tools
CNC controller: KND, GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
Standard Accessories:
All machines and standard accessories supplied by Nantong AJ Industry Limited except couplings, cables, electric panel, CNC system and motors, auxiliary panel, and transformer (motor housing supplied by Nantong AJ Industry Limited).

Fanuc 0i TF control system

Taiwan Spindle: 8000rpm

X/Y/Z axes: Fanuc servo drive motor

Main motor: Fanuc spindle motor

24 tools Umbrella type

USB for information transfer

Rough cutting of thread

Full closed cover

Automatic lubrication

Coolant system,

Work lamp,

Tri-color indication lamp

Air gun

Heat exchanger in cabinet

3-Axis linear guideway from Taiwan Hiwin

Ball leadscrew from taiwan Hiwin

Enhance your 5 Axis VMC CNC Milling Machine with optional accessories from Nantong AJ Industry Limited. Elevate your precision machining capabilities with our advanced CNC technology.

Automatic chip conveyor & chip bucket (Chain type)

Spindle direct driven, speed 12000 rpm

Spindle center water spray

Air conditioner for electricity cabinet

Automatic chip conveyor & chip bucket (Screw type)

Spindle oil cooling

Nitrogen balance cylinder

4th Axis or 5th Axis

Export Certificate
Company Name: Nantong AJ Industry Limited
Product Name: 5 Axis VMC CNC Milling Machine Equipment
Keywords: Vertical CNC Machine Tool, High Precision CNC Machine, Automated Milling System, 5 Axis Milling Machine
