Product Description
Product Description
Product DescriptionHY4320A HDT/Vicat Tester is used to determine the heat distortion temperature (HDT) and Vicat softening point of plastic materials.StandardASTM D1525, D648ISO 2507, 75, 306GB/T 8802, 1633, 1634Note: For more standards, please contact usSpecificationModelAT432ATemperature rangeRT~300℃ Heating speed120℃/h [(12±1)℃/6min] 50℃/h [(5±0.5)℃/6min]Max. temperature error0.5℃Distortion range3mmMax. distortion error0.01mmWorking position3 (4 or 6 optional)Heating mediumMethyl silicone oil or transformer oilHeating power3kw Cooling methodBelow 150℃: water coolingOver 150℃: air coolingPower supplyAC220V, 10A, 50HzDetails & Features★ AT432A is horizontal type★ LCD display, 7”Touch screen control to set heating rate, displacement, calculate weight etc.★ Adopts SCM control, can set upper limit for temperature, high temperature accuracy★ Uses digital micrometer, convenient to read★ It also can connect to PC and perform all the machine on PC★ 3 or 4 or 6 or customized working positions can be chosenOur CompanyHistorySince 1982 with more than 20 years’ experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most productPacking & DeliveryPackagingPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. PaymentPayment TermT/TEXW30% T/T in advance, paid the balance before shipmentFOBCFR(C&F)30% T/T in advance, paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 5000usdWest UnionDelivery Time7~10days after receiving payment for one containerContacting Us
>>
