Product Details
Product Description
Product Description
Principle Characteristics
Based on the thermal principle, the enclosed probe contains two resistors, one of which is heated as the detection resistance and the other is not heated as the reference resistance. When the medium flows, the heat on the heating resistance is taken away, the resistance value is changed, and the difference between the two resistances is used as the basis for judging the flow rate.
Product Application
Gas-liquid dual type is used for pneumatic and hydraulic systems,can be used for circulating water, cutting fluid and lubricating oil flow.
Special Features：
Reliable flow monitoring of liquid media
Switching and analogue outputs for flow, temperature and diagnostics
Easily parameterisable via the local display
Free from wear, without any moving parts in the medium
Technical Parameters
*Set the range： 1...150cm/s(water），3...300cm/s(oil），20...2000cm/s(air）
*Signal output： PNP,NPN，relay，Normally open + normally closed（SPDT）
*The power supply： 24V±20%VDC or 230V±15%VAC
*Current is switched on：Maximum 400mA(PNP or NPN), maximum 4A (relay)*
*No-load current： Maximum 80mA
*Flow indicator： LED row (6)
*Set way： Potentiometer setting
*Pressure range： 100bar
*The temperature gradient：≤4°C/s
*The response time： 1-13s,Typical values 2s
*Initialization time： 8s
*Electric protection：Invert, short circuit
Overload protection
*Protection grade： IP67
*Medium temperature：-20...80°C
*The environment temperature：-20...80°C
*Storage temperature： -20...100°C
*Connection mode：M12 plug-in/direct attachment line
*Material：
probe： Stainless steel
shell： PBT
weight： 0.4kg
NOIKE support OEM !
detection, and pump idling protection
>>
